Toshiba Tecra A4-S312TD Specifications

Tecra A4 Detailed Product Specification
Model Name Description
A4-S312TD Microsoft® Windows® XP Professional, Intel Pentium® M Processor 740, 256MB
DDR2, 40GB SATA, CD-RW/DVD-ROM, 15.4" widescreen WXGA, Intel Graphics
Media Accelerator 900, Integrated Wireless Antenna, IEEE® 1394, 1Gbps Ethernet, S-
Video, 6-in-1 card reader/writer, 1 year limited warranty
2
Operating System
• Microsoft® Windows® XP Professional
3
Processor and Chipset
• Choice of processors:
o Intel® Pentium® M Processor 740
1.73GHz, 2MB L2, 533MHz FSB
o Intel® Pentium® M Processor 760
2.00GHz, 2MB L2, 533MHz FSB
o Intel® Pentium® M Processor 770
2.13GHz, 2MB L2, 533MHz FSB
o Intel® Pentium® M Processor 780
2.26GHz, 2MB L2, 533MHz FSB
• Choice of chipset:
o Mobile Intel 915GM/PM Express Chipset
4
Memory
• Configured with 256MB DDR2 SDRAM
• 256MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB,
or 1024MB PC4200 DDR2 533MHz SDRAM, dual-channel
support requires two memory modules of same capacity and
clock speed
5
Hard Disk Drive
• Choice of: 40GB (5400 RPM), 60GB (5400 RPM), or 80GB
(5400RPM); Serial-ATA (SATA) hard disk drive; 9.5mm height;
user removable
Fixed Optical Disk Drive
• CD-RW/DVD-ROM drive maximum speed and compatibility:
o CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read)
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
maximum speed and compatibility:
o CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read), DVD-R (Single Layer,
8x:write), DVD-R (Double Layer, 2x: write), DVD-RW
(4x:write), DVD+R (Single Layer, 2x:write), DVD+R
(Double Layer, 2.4x:write), DVD+RW (4x:write), DVD-
RAM (3x:write)
6
Display
• 15.4" diagonal widescreen TFT active-matrix LCD display at
1280x800 native resolution (WXGA)
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
• 15.4" diagonal widescreen TFT active-matrix LCD display at
1680x1050 native resolution (WSXGA+)
7
Graphics
• Intel Graphics Media Accelerator 900 with 8MB-128MB dynamically
allocated shared graphics memory; or
• PCI-Express™ x16 graphics system with:
• ATI MOBILITY™ RADEON® X600 with 64MB DDR discrete
graphics memory
1
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
TECRA A4-S312TD BTO Rev. 1.02 2005-10-17 KK T20050810 CB1.00
Part Number
PTA42U-019012
• NVIDIA GeForce™ Go 6600 with 128MB DDR discrete graphics
memory
Sound
• Analog Devices AD1981B integrated 16-bit stereo software sound
o Supports 3D Sound, Direct 3D Sound, DirectSound,
Direct Music, MIDI (playback)
• Built-in microphone
• Sound Volume Control Dial
• Built-in stereo speakers
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control
panel
o Presentation button to quickly connect to projectors
Communications
• Toshiba V.92 software modem
• Marvell Network Connection - 10/100/1000 Base-TX Ethernet
• Choice of Wireless-LAN:
o Integrated Intel Pro/Wireless Network Connection
2200BG (802.11b/g)
o Integrated Intel Pro/Wireless Network Connection
2915ABG (802.11a/b/g)
o Atheros® 802.11b/g wireless-LAN supporting Atheros
SuperG™ technology
o Atheros® 802.11a/b/g wireless-LAN supporting Atheros
SuperAG™ technology
• Optional Integrated Bluetooth® version 2.0 plus Enhanced Data
Rate (EDR) with Toshiba Bluetooth driver software
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• ExpressCard slot supporting ExpressCard/34 and ExpressCard/54
• 6-in-1 Bridge Media Adapter (Secure Digital, miniSD™ (with
adapter) Memory Stick™, Memory Stick PRO™, SmartMedia™,
Multi Media Card, xD Picture Card [shared slots])
Ports
• RGB (monitor) port
• TV-out (S-Video)
• i.LINK™ IEEE-1394
• 3 Universal Serial Bus (USB) ports (v2.0)
• External Microphone jack
• Headphone jack
• RJ-45 LAN port
UPC
32017440920
8
9
Page 1 of 5
