P5503
GB | Mechanical Timer Socket
Daily Plug-In Mechanical Timer serves to switch power supply 230 V~ in the required time. This timer
can be used to set up to 48 On/Off periods a day.

Specification

Power Supply
Max. Load
Temperature of environment
Total accuracy of timer

Setting the time

Turn the dial clockwise (as per indicating arrows) until the arrow-located at the top right of the
centre dial, is pointing to the correct time. Ensure that the manual override switch on the top of the
unit is set to the position.
Each segment represents 15 minutes: 4 segments = 1 hour.

Setting of the required programme

1. Using your finger, a pen or screwdriver pull up all the segments on the edge of the rotating disk in
the required closured time. One segment switches the timer for 15 minutes (4 segments = 1 hour).
2. The switch on the side of the timer switch to the down position
to the programme.
3. Plug the timer into the supply network 230 V~/50 Hz
4. Insert the appliance plug into the Timer plug
The switched mode of the socket is shown by red LED
The upper position I - socket is still switched independently of programme.
The down position – switch timer works according to the programme.

SAFETY WARNINGS

• Max. inductive load 2 A, max. resistive load 16 A. Do not connect higher loads.
• Do not disassemble the timer socket or submerse it in water or other liquids.
• When cleaning the timer socket, always unplug it from power first. Then clean it using a dry cloth.
• Use the timer socket in dry, indoor areas only.
• This appliance is not intended for use by persons (including children) whose physical, sensory or
mental disability or lack of experience and expertise prevents safe use, unless they are supervised
or instructed in the use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
• Any use of the device not listed in the previous sections of the manual will result in damage to
the product and could present danger in the form of a short circuit, injury by electric current,
etc. The device must not be modified or otherwise restructured! Safety warnings must be
followed unconditionally.
Do not dispose with domestic waste. Use special collection points for sorted waste. Contact
local authorities for information about collection points. If the electronic devices would be
disposed on landfi ll, dangerous substanoes may reach groundwater and subsequently food
chain, where it could affect human health.
| TF-16
230 V~, 50 Hz
16 (2) A, 3 680 W
0 up to +55 °C
±6 mins per day
1
the switch works according
