Matsusada Precision R4GN Series Basic Instruction Manual

R4GN series
Basic Instruction Manual

1. Introduction

This manual summarizes the main features of the R4GN
series. Detailed descriptions and precautions are
provided in the instruction manual. The product
generates high-voltage and high-energy. Therefore,
wrongly handling or operating the product may result in
death or serious injury and maybe property damage as
well. Use the product after understanding how to use it
properly. Please note that we will not be held responsible
for any damage or loss caused by not following the
warnings, cautions, and procedures described in the
manual.
Instruction Manual on the Web
The latest instruction manual is available
on our Web site.
You can also access our web site with
the QR code on the right.
If the download is unavailable, please
contact our sales representatives.
Keep the manual with you so that you can read it
whenever you want.
https://www.matsusada.com/product/

Table of Contents:

1. Introduction ........................................................ 1
2. Accessories .......................................................
3. For Safe Use of the Product .............................. 2
4. Initial Inspection ................................................. 4
5. A Brief Description from Power-on to Output
6. Key Features and Protections ............................ 4
7. External View ...................................................... 4
8．Remote Interface Connector (TB1) ................... 5
9. Function Setting Switch (SW1) ........................... 5
10. Startup Menu .................................................... 6
11. LOCK Function ................................................. 6
12. Error List ........................................................... 6
13. Troubleshooting ................................................ 7
*217.9.296*
B/N: 217.9.296 Rev. 0.0
1
4

2. Accessories

After unpacking the box, check the following accessories
are enclosed with the unit body. If the accessories are
different, missing, or broken, please contact us
immediately.
<Accessories>
□
Basic Instruction Manual
□
AC input cable
□
MIL 26-pin male connector
□
MIL 26-pin semi-cover
<Optional Accessories for -LGmb>
□
CO-M cable
<Optional Accessories for -LGob>
□
CO-OPT cable
<Optional Accessories for -LCk>
□
CC-Link communication connector
<Optional Accessories for -LMi>
□
Connector for RS-485
1
1 pc
1 pc
1 pc
2 pc
1 pc
1 pc
1 pc
1 pc
R4GN series
