Matsusada Precision RK Series Basic Instruction Manual

Basic Instruction Manual

1. Introduction

This manual summarizes the main features of the
RK/REK/REKJ series.
precautions are provided in the instruction manual. The
product generates high-voltage
Therefore, wrongly handling or operating the product may
result in death or serious injury and maybe property
damage as well. Use the product after understanding
how to use it properly. Please note that we will not be
held responsible for any damage or loss caused by not
following the warnings, cautions, and procedures
described in the manual.
Instruction Manual on the Web
The latest instruction manual is available
on our Web site.
You can also access our website with
the QR code on the right.
If the download is unavailable, please
contact our sales representatives.
Keep the manual with you so that you can read it
whenever you want.
https://www.matsusada.com/product/

Table of Contents:

1. Introduction ........................................................ 1
2. Accessories .......................................................
3. For Safe Use of the Product .............................. 2
4. Initial Inspection ................................................
5.
Operation Procedure from POWER ON to OUTPUT
6. Main Features and Protections .........................
7 External View ...................................................... 4
8 Startup Menu ....................................................
9 LOCK .................................................................
10 Multiple Settings ...............................................
11 Error Display ....................................................
12 Troubleshooting ...............................................
*167.9.247*
B/N: 167.9.247 Rev. 0.5
series
Detailed descriptions
and high-energy.
......... 4

2. Accessories

After unpacking the box, check the following accessories
are enclosed with the unit body. If the accessories are
and
different, missing, or
immediately.
<Accessories>
□ Basic Instruction Manual (this one)
□ Remote connector cover
□ D-Sub25Pin male connector
* It is attached to the unit body of
REK1.2 to 5.5 kW models for shipment.
□ AC input cable
* It is supplied to the RK/REKJ series.
(For the REK series, it is optional.)
□ CO-M cable
* It is supplied for models with no
functional setting switch. As for models
with options, it is not supplied even with
the functional setting switch.
□ Output terminal cover
* Only attached to REKJ800-1 model.
1
<Accessory for -LGob option installed>
4
□ Optical fiber cable
4
<Accessory for -LMi option installed>
□ Connector for RS-485
5
6
6
6
7
1
broken, please contact
1 pc
1 set
1 pc
1 pc
1 pc
1 set
1 pc
1 pc
RK/REK/REKJ series
us
