General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
Boom kit.
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON, PLEASE CALL
1-800-831-0027
MONDAY-FRIDAY, 8:00 AM TO 5:00 PM CST
If you should have a question or experience a problem with
your Fimco Industries Product: Visit our website @
www.fimcoindustries.com or call the Toll free number above. Our
technical support representatives will be happy to help you.
In most cases a customer service rep. can resolve
the problem over the phone.
To obtain prompt, efficient service, always remember to give the
following information....
• Correct Part Description and/or part number
• Model number and Serial Number
Part descriptions and numbers can be obtained from the
illustrated parts list section(s) of this manual.
Retain a copy of your receipt for your unit, as it will be required
to validate any warranty service.
Warranted against manufacturer or workmanship defects from
date of purchase with copy of receipt:
Homeowner Usage: One Year.
Commercial Usage: 90 Days.
OWNER'S MANUAL
Model: BK-1 (5300954)
(2-Nozzle Boom Assembly w/Mounting Brackets
)
WARNING:
To reduce the risk of injury, the
user must read and understand the operator's
manual before using this product.
WARNING:
Cancer and Reproductive Harm.
www.P65Warnings.ca.gov
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5004586
(11/22)]
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fimco BK-1
Summary of Contents for Fimco BK-1
- Page 1 Warranted against manufacturer or workmanship defects from date of purchase with copy of receipt: www.fimcoindustries.com 1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049 Homeowner Usage: One Year. Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440 Commercial Usage: 90 Days.
- Page 2 Assembly Instructions ............2 Winter Storage ..............4 Operation................3 Boom Exploded View/Parts List ......... 5 Calibration ................3 Warranty ................6 Model: BK-1 (5300954) (2-Nozzle Boom Assembly w/Mounting Brackets) Technical Specifications • 2-Nozzle Boom Assembly • 80” Spray Swath •...
- Page 3 Testing the Sprayer NOTE: It is VERY important to test the sprayer, after attaching any boom with plain water before actual spraying is attempted. This will enable you to familiarize yourself with the sprayer and check for leaks without possibility of losing any expensive chemicals. Fill the tank about 1/2 full with plain water.
- Page 4 Drain and then refill half full, add the recommended amount of a good quality tank cleaner, such as FIMCO Tank Neutralizer and Cleaner. (If no tank cleaner is available, you may substitute dish soap for this step, about 1-2 oz.
- Page 5 Exploded View/Parts List: BK-1 (5300954) See Boom Breakdown Below Nozzle Assembly 2-Nozzle Boom QJ (#5277774) Based on the minimum overlap required to obtain uniform distribution with 120° tips and 40” spacing. Suggested Minimum Spray Height: 18”-20” above what is being sprayed (to plant, not ground).
- Page 6 WHAT REMEDIES ARE AVAILABLE UNDER THIS LIMITED WARRANTY. If the conditions set forth above are fulfilled and the Equipment or any part thereof is found to be defective, Fimco, Ind. shall, at its own cost, and at its option, either repair or replace the defective Equipment or part.
