Caroma Family D-Shape Installation Instructions

Family D-Shape Toilet seat
1
Push metal toggle through pan hole.
4
Ensure the rubber pads are tted to the underside
of the hinge mounting posts, insert the elongated
washer and loosely fasten to the pan.
7
Push the button at the rear of the seat to release
and remove the seat taking care not to move the
hinge posts.
IMPORTANT : Never use abrasive or harsh chemical cleaners. Wipe seat with warm soapy water to maintain surface nish.
2
Realign handles and pull upwards while pushing
locking bush down into pan hole.
5
Align the hinge posts with the corresonding holes
in the seat assembly and push down until it clicks.
8
Fully tighten the bolts using the hex key provided.
Installation Instructions
3
Break o handles ush with locking bush. Trim
excess with a pair of side cutters if required.
6
Adjust seat to desired position
9
Slide the stainless steel covers over the hinge posts
and t the seat.
on pan.
