Tosot TW09HQ1C8D Service Manual page 9

Model
Product Code
Rated Voltage
Power Supply Rated Frequency
Phases
Power Supply Mode
Cooling Capacity(Min~Max)
Heating Capacity(Min~Max)
Cooling Power Input(Min~Max)
Heating Power Input(Min~Max)
Cooling Power Current
Heating Power Current
Rated Input
Rated Current
Air Flow Volume(SH/H/M/L)
Dehumidifying Volume
EER
COP
SEER
HSPF
Application Area
Model of indoor unit
Indoor Unit Product Code
Fan Type
Diameter Length(DXL)
Fan Motor Cooling Speed(SH/H/M/L)
Fan Motor Heating Speed(SH/H/M/L)
Output of Fan Motor
Fan Motor RLA
Fan Motor Capacitor
Evaporator Form
Pipe Diameter
Indoor Unit
Row-fin Gap
Coil Length (LXDXW)
Swing Motor Model
Output of Swing Motor
Fuse
Sound Pressure Level(SH/H/M/L)
Sound Power Level(SH/H/M/L)
Dimension (WXHXD)
Dimension of Carton Box (LXWXH)
Dimension of Package (LXWXH)
Net Weight
Gross Weight
6
V~
Hz
Btu/h
Btu/h
W
W
A
A
W
A
CFM
Pint/h
(Btu/h)/W
(Btu/h)/W
2
yd
inch
r/min
r/min
W
A
μF
inch
inch
inch
W
A
dB (A)
dB (A)
inch
inch
inch
Ib
Ib
TW12HQ1C8D
CB456000900_L59684
208/230
60
1
Outdoor
12000(3753~12500)
13000(3924~14000)
1300(410~1350)
1250(380~1500)
5.8
5.6
1500
6.7
400/318/253/194
2.96
9.23
10.40
16.00
9.00
19.14-28.70
TW12HQ1C8D/I
CB456N00900_L59684
Cross-flow
Φ3 7/8X25
1350/1200/1000/800/-
1350/1200/1000/900/-
20
0.31
1.5
Aluminum Fin-copper Tube
Φ3/16
2-1/16
25X7/8X12 1/16
MP24BA
1.5
3.15
45/39/35/29/-
55/49/45/39/-
33 1/4X11 3/8X8 1/4
36 1/8X11X14 5/16
36 1/4X11 1/16X15
22.05
26.46
Technical Information
Service Manual
