Tosot TW09HQ1C8D Service Manual page 25

Model
Product Code
Rated Voltage
Power Supply Rated Frequency
Phases
Power Supply Mode
Cooling Capacity(Min~Max)
Heating Capacity(Min~Max)
Cooling Power Input(Min~Max)
Heating Power Input(Min~Max)
Cooling Power Current
Heating Power Current
Rated Input
Rated Current
Air Flow Volume(SH/H/M/L)
Dehumidifying Volume
EER
COP
SEER
HSPF
Application Area
Model of indoor unit
Indoor Unit Product Code
Fan Type
Diameter Length(DXL)
Fan Motor Cooling Speed(SH/H/M/L)
Fan Motor Heating Speed(SH/H/M/L)
Output of Fan Motor
Fan Motor RLA
Fan Motor Capacitor
Evaporator Form
Pipe Diameter
Indoor Unit
Row-fin Gap
Coil Length (LXDXW)
Swing Motor Model
Output of Swing Motor
Fuse
Sound Pressure Level(SH/H/M/L)
Sound Power Level(SH/H/M/L)
Dimension (WXHXD)
Dimension of Carton Box (LXWXH)
Dimension of Package (LXWXH)
Net Weight
Gross Weight
22
V~
Hz
Btu/h
Btu/h
W
W
A
A
W
A
CFM
Pint/h
(Btu/h)/W
(Btu/h)/W
2
yd
inch
r/min
r/min
W
A
μF
inch
inch
inch
W
A
dB (A)
dB (A)
inch
inch
inch
Ib
Ib
TW12HQ2C2D
CB439005601_X18545
208/230
60
1
Outdoor
12000(3100~13000)
13000(2400~14000)
960(200~1350)
1100(400~1400)
4.50
5.50
1400
6.3
400/288/241/171
2.96
12.5
11.82
22.00
10.10
19.14-28.70
TW12HQ2C2DI
CB439N05601_X18545
Cross-flow
Φ3 55/64X25
1400/1200/1050/800
1400/1200/1000/900
20
0.09
/
Aluminum Fin-copper Tube
Φ3/16
2-1/18
25X7/8X12 1/16
MP24BA
1.5
3.15
45/39/35/29
55/49/45/39
33 1/4X11 3/8X8 1/4
36 1/8X11X14 5/16
36 1/4X11X15
22.05
26.46
Technical Information
Service Manual
