Tosot TW09HQ1C8D Service Manual page 119

NO.
Product Code
1 Front Panel
2 Display Board
3 Front Case Assy
4 Helicoid Tongue
5 Left Axile Bush
6 Rear Case assy
7 Drainage Hose
8 Ring of Bearing
9 O-Gasket sub-assy of Bearing
10 Evaporator Support
11 Cold Plasma Generator
12 Evaporator Assy
13 Wall Mounting Frame
14 Cross Flow Fan
15 Fan Motor
16 Connecting pipe clamp
17 Rubber Plug (Water Tray)
18 SteppingMotor
19 Crank
20 Electric Box Assy
21 Axile Bush
22 Terminal Board
23 Jumper
24 Main Board
25 Electric Box Cover Sub-Assy
26 Shield Cover of Electric Box Cover
27 Electric Box Cover
28 Power Cord
29 Connecting Cable
30 Connecting Cable
31 Remote Controller
32 Test Board Assy
33 Guide Louver
34 Air Louver 1
Above data is subject to change without notice.
116
Description
Part Code
TW09HQ2C2DI
CB439N05801_X18545
27230006884
30565281
00000200045
26112436
10512037
00000100093
05230014
26152022
76512051
24212174
/
01002000030
01252484
10352056
150104060029
2611216401
76712012
1521210710
73012005
100002003835
10542036
42011233
4202021909
30138001018
0140206501
01592150
2011220701
/
/
/
305001000085_TOSOT
/
1051293101
10512723
Service Manual
Qty
1
1
1
1
1
1
1
1
1
1
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
1
0
1
1
Installation and Maintenance
