Model
Product Code
Rated Voltage
Power Supply Rated Frequency
Phases
Power Supply Mode
Cooling Capacity(Min~Max)
Heating Capacity(Min~Max)
Cooling Power Input(Min~Max)
Heating Power Input(Min~Max)
Cooling Power Current
Heating Power Current
Rated Input
Rated Current
Air Flow Volume(SH/H/M/L)
Dehumidifying Volume
EER
COP
SEER
HSPF
Application Area
Model of indoor unit
Indoor Unit Product Code
Fan Type
Diameter Length(DXL)
Fan Motor Cooling Speed(SH/H/M/L)
Fan Motor Heating Speed(SH/H/M/L)
Output of Fan Motor
Fan Motor RLA
Fan Motor Capacitor
Evaporator Form
Pipe Diameter
Indoor Unit
Row-fin Gap
Coil Length (LXDXW)
Swing Motor Model
Output of Swing Motor
Fuse
Sound Pressure Level(SH/H/M/L)
Sound Power Level(SH/H/M/L)
Dimension (WXHXD)
Dimension of Carton Box (LXWXH)
Dimension of Package (LXWXH)
Net Weight
Gross Weight
10
V~
Hz
Btu/h
Btu/h
W
W
A
A
W
A
CFM
Pint/h
(Btu/h)/W
(Btu/h)/W
2
yd
inch
r/min
r/min
W
A
μF
inch
inch
inch
W
A
dB (A)
dB (A)
inch
inch
inch
Ib
Ib
TW24HQ1C8D
CB456000200_L59684
208/230
60
1
Outdoor
22000
23000
2260
2300
10.03
10.20
2750
11.98
706/647/588/530
5.28
9.73
10.00
16.00
9.00
32.29-50.23
TW24HQ1C8D/I
CB456N00200_L59684
Cross-flow
Φ4 1/4×32 7/10
1250/1100/900/800
1150/1000/900/850
30
0.32
3
Aluminum Fin-copper Tube
0.286
2-1/17
33 1/4×1×13 1/2
MP35CJ
2.5
3.15
48/44/40/36/-
58/54/50/46/-
42 7/16X12 13/16X9 11/16
45X16 1/8X13 3/16
45 3/16X16 1/4X13 3/4
37.5
45.2
