Overhead Closer
Introduction
Briton 121CE is a compact, fixed power
size EN 3 door closer suitable for
light to medium duty applications.
This cost effective closer exhibits
the characteristics of performance,
durability and quality that one
has come to expect from a Briton
door closer, and is certified in all
applications.
Features & Functions
ƒ
Fixed power size EN 3
ƒ
Certified for door mount pull,
parallel and transom mount
push side applications
ƒ
Pressure die cast aluminium body
ƒ
Screw thread forged steel armset
ƒ
Adjustable closing speed & latch
action
ƒ
Universal fittings for door mount,
transom and parallel arm mount
ƒ
Fitting template for quick,
accurate installation
ƒ
Optional hold-open armset
available (not to be used on fire
doors)
ƒ
Suitable for fire door applications
ƒ
Available in a choice of sprayed
finishes
DC-001
DATASHEET
ISSUE DATE: June 2021
DOOR CONTROLS
Certification
CE Marked to EN 1154 (2812-CPR-AD0248)
UKCA Marked to EN 1154 (1121-CPR-UK-AD7602)
Fire tested to EN 1634-1 for use on fire doors up to 2hr timber
Certifire Approved (CF390)
Environmental Product Declaration in accordance with ISO 14025 and EN 15803
DoP available at www.britondops.co.uk
Allegion (UK) Limited
35 Rocky Lane, Aston, Birmingham B6 5RQ
T:
+44 (0) 330 8080 617
E:
contactuk@allegion.com
121CE
1110
1110.C
1110.S
www.briton.co.uk
Advertisement
Related Manuals for Briton 121CE
Summary of Contents for Briton 121CE
- Page 1 121CE 1110 Overhead Closer 1110.C 1110.S Introduction Briton 121CE is a compact, fixed power size EN 3 door closer suitable for light to medium duty applications. This cost effective closer exhibits the characteristics of performance, durability and quality that one...
- Page 2 DOOR CONTROLS Overhead Closer Briton 121CE Product features Product references 121CE Closer type Projecting/scissor arm CE marked Fixed closing power EN size Door limits (width/weight) 950mm/60kg Adjustment type n/a - fixed power Maximum angle of opening 180˚ Adjustable closing speed & latch action...
- Page 3 DOOR CONTROLS 121CE General Maintenance Door controls Types of maintenance In research, Allegion has identified Much of the routine maintenance recommended consists of a combination of that 95% of all problems associated visual and mechanical checks, cleaning and lubrication. Look out for the icons with overhead door closers can opposite which provide a ‘quick glance’...
- Page 4 DOOR CONTROLS Closer Maintenance WEEKLY Release the door from the fully open position and ensure that it closes fully into the frame. Ensure the latch (if fitted) engages fully into the strike plate. Repeat the process a few times from different angles of opening to ensure the door closes consistently each time.
