Overhead Closer
Introduction
The 2130B is a spring adjustable power size EN 2-6
overhead door closers with backcheck. Certified for door
and frame mount applications, this flexible closer combines
engineering quality and good looks to create a truly
versatile solution for any severe or heavy duty application.
Features & Functions
ƒ
Spring adjustable power size EN 2-6
ƒ
Capable of meeting BS8300
requirements
ƒ
Certified in door mount pull and
transom mount push side applications
(EN 2-6)
ƒ
Certified in parallel arm mount
(2130B EN 2-5) (2130BD EN 1-5)
ƒ
Universal fittings for door mount,
transom and parallel arm mount
ƒ
Adjustable closing speed & latch
action
ƒ
Built-in adjustable backcheck to
prevent damage to the door and
frame
ƒ
Pre-assembled arm and bracket
simplifies assembly, increasing
speed and accuracy of installation
ƒ
Unique self-adhesive 'Accufit'
installation template and mounting
plate with dowel fixings to position
the closer body ensure a quick,
simple and accurate installation
ƒ
Suitable for fire door applications
ƒ
Classic cover conceals fixings and
adjustment screws
DOOR CONTROLS
Certification
CE Marked to EN 1154 (2812-CPR-AD0031)
UKCA Marked to EN 1154 (1121-CPR-UK-AD7578)
Fire tested to EN 1634-1 for use on fire doors up to 2hr timber / 1hr steel [* May be
fitted to fully insulated steel based doorsets or uninsulated steel based doorsets
where the closer is fitted to the fire risk face only].
Certifire Approved (CF111)
(*
Briton 2130B only)
Environmental Product Declaration in accordance with ISO 14025 & EN 15804
DoP available at www.doorhardware-online.co.uk
2130B
2130BD
2130B.C.SES
*
*
Advertisement
Related Manuals for Briton 2130B
Summary of Contents for Briton 2130B
- Page 1 2130B Overhead Closer 2130BD Introduction The 2130B is a spring adjustable power size EN 2-6 overhead door closers with backcheck. Certified for door and frame mount applications, this flexible closer combines engineering quality and good looks to create a truly versatile solution for any severe or heavy duty application.
-
Page 2: Door Controls
DOOR CONTROLS Overhead Closer Briton 2130B & 2130BD Product features Product references Standard 2130B 2130BD Available as an Closer type Projecting/scissor arm Projecting/scissor arm option/variant CE marked Closing power EN size 2 - 6 2 - 6 Accessories & Parts... - Page 3 DOOR CONTROLS 2130B Overhead Closers 2130BD REGULAR FIXING ( FI POWER SIZE 2 - 6 Installation dimensions Regular Application [Fig.1 ] Door mounted application for power sizes EN 2 - 6 EGULAR FIXING ( FI TRANSOM FIXING ( FIG.61 )
-
Page 4: General Maintenance
DOOR CONTROLS 2130B General Maintenance 2130BD Door controls Types of maintenance In research, Allegion has identified Much of the routine maintenance recommended consists of a combination of that 95% of all problems associated visual and mechanical checks, cleaning and lubrication. Look out for the icons with overhead door closers can opposite which provide a ‘quick glance’... - Page 5 DOOR CONTROLS Closer Maintenance WEEKLY Release the door from the fully open position and ensure that it closes fully into the frame. Ensure the latch (if fitted) engages fully into the strike plate. Repeat the process a few times from different angles of opening to ensure the door closes consistently each time.
