Overhead Closer
Introduction
Briton 2130B.T is a spring adjustable power size EN 2-4 track
arm door closer with adjustable closing speed, latch action and
backcheck.
This combination of engineering quality and good looks creates a
truly versatile architectural solution for any severe of heavy duty
application.
Features & Functions
ƒ
Spring adjustable power size EN 2-4
ƒ
Slide track application
ƒ
Certified for door mount pull side
fixing
ƒ
Adjustable closing speed & latch
action
ƒ
Built-in adjustable backcheck to
prevent damage to the door and
frame
ƒ
Unique self-adhesive 'Accufit'
installation template and mounting
plate with dowel fixings to position
the closer body ensures a quick,
simple and accurate installation
ƒ
All-over Classic cover conceals
fixings and adjustment screws to
prevent tampering
ƒ
Suitable for fire door application
DOOR CONTROLS
2130B.T.SES
Certification
UKCA Marked to EN 1154 (1121-CPR-UK-AD7579)
CE Marked to EN 1154 (2812-CPR-AD0032)
Certifire Approved (CF111)
Fire tested to EN 1634-1 for use on fire doors up to 2hr timber / 1hr steel [* May be
fitted to fully insulated steel based doorsets or uninsulated steel based doorsets
where the closer is fitted to the fire risk face only].
Environmental Product Declaration in accordance with ISO 14025 & EN 15804
DoP available at www.doorhardware-online.co.uk
2130B.T
*
Advertisement
Related Manuals for Briton 2130B.T
Summary of Contents for Briton 2130B.T
- Page 1 DOOR CONTROLS 2130B.T Overhead Closer Introduction Briton 2130B.T is a spring adjustable power size EN 2-4 track arm door closer with adjustable closing speed, latch action and backcheck. This combination of engineering quality and good looks creates a truly versatile architectural solution for any severe of heavy duty application.
-
Page 2: Door Controls
DOOR CONTROLS Overhead Closer Briton 2130B.T n Available as an option/variant Standard Product features Product references 2130B.T Closer type Track arm UKCA & CE marked Closing power EN size 2 - 4 Accessories & Parts Adjustment type Spring power 2130.T.AP... - Page 3 DOOR CONTROLS 2130B.T Overhead Closers APPLICATION A - DOOR FIXING - PULL SIDE POWER SIZE 2 - 4 Installation dimensions Door Mount Door mounted pull side for power sizes EN 2 - 4 APPLICATION B - TRANSOM FIXING - PUSH SIDE...
-
Page 4: General Maintenance
DOOR CONTROLS 2130B.T General Maintenance Door controls Types of maintenance In research, Allegion has identified Much of the routine maintenance recommended consists of a combination of that 95% of all problems associated visual and mechanical checks, cleaning and lubrication. Look out for the icons with overhead door closers can opposite which provide a ‘quick glance’... - Page 5 DOOR CONTROLS Closer Maintenance WEEKLY Release the door from the fully open position and ensure that it closes fully into the frame. Ensure the latch (if fitted) engages fully into the strike plate. Repeat the process a few times from different angles of opening to ensure the door closes consistently each time.
