Overhead Closers
Introduction
Briton 1110 is an industry leading
compact, template adjustable size
EN 2-4 medium duty door closer
suitable for living accommodation
and commercial spaces. Available
with simple trimplate cover or softline
all-over cover to conceal fixings and
adjustment screws.
Features & Functions
ƒ
Template adjustable closing
power size EN 2-4 (regular) EN 3
(parallel arm) applications
ƒ
Certified for door mount, transom
and parallel arm applications
ƒ
Cast aluminium body
ƒ
Adjustable closing speed and
latch action
ƒ
Universal fittings for door mount,
transom and parallel arm mount
ƒ
Fitting template for quick,
accurate installation
ƒ
Screw thread armset in forged
steel for additional strength and
durability (supplied with trimplate
variants)
ƒ
All-over cover variants supplied
with flatform arm pack
ƒ
Snap joint arm connection for quick
and easy installation and
maintenance
ƒ
Trimplate option a cost effective
means of concealing fixing and
adjustment screws
ƒ
Suitable for fire door applications
ƒ
Optional hold-open armset (not
to be used on fire doors)
ƒ
Available in a choice of sprayed
finishes and plated cover and arm
options
DC-003
DATASHEET
ISSUE DATE: June 2021
DOOR CONTROLS
1110.SES
Certification
CE Marked to EN 1154 (2812-CPR-AD0033)
UKCA Marked to EN 1154 (1121-CPR-UK-AD7580)
Fire tested to EN 1634-1 for use on fire doors up to 2hr timber / 4hr steel [* May be
fitted to fully insulated steel based doorsets or uninsulated steel based doorsets
where the closer is fitted to the fire risk face only].
Certifire Approved (CF388)
Environmental Product Declaration in accordance with ISO 14025 and EN 15803
DoP available at www.britondops.co.uk
Allegion (UK) Limited
35 Rocky Lane, Aston, Birmingham B6 5RQ
T:
+44 (0) 330 8080 617
E:
contactuk@allegion.com
1110.S.SSS
Options with Softline (S) cover shown in Satin
Stainless Steel finish.
*
www.briton.co.uk
1110
1110.S
