Callaway MICRO PRO Manual

4. Unit of Measure - To change the unit of measure from Yards
to Meters, start with the device powered off. Then HOLD the
Mode Button for 3 sec. The unit of measure is indicated by a
"Y" or "M" shown directly to the right of the distance displayed.
SLOPE FUNCTION
To turn Slope on/off, press the "S" button on the top of the unit
1. If GREEN is flashing: Slope function is off. The Laser is
tournament legal when the slope is turned off.
2. RED is flashing: Slope function is enabled. Slope adjusted
If
yardage will be displayed after every time the laser is fired.
The Laser is not tournament legal when the slope is enabled.
Front indicator
lights:
SLOPE ON
CHARGING
1. Insert the USB-C charger end into the Micro Pro & then insert
the USB end of the charging cord into a USB charging port or
AC adapter (not included). The recommended USB charging
rate is 5V, 1A.
2. A complete full charge will take about 6 hours. the indicator
light will turn green when charging is completed.
3. A full charge should last 100+ rounds of golf
Caution: Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
SLOPE OFF
CALLAWAY
MICRO PRO
LASER RANGEFINDER
RANGEFINDER DIAGRAM
A. Eye Piece
B. Diopter Adjustment
C.
Power Button
D. Mode Button
E.
Slope Button
F. Charging Port
LCD DISPLAY
A.
Zero-In Aiming Square
B. Laser Indicator
C.
P.A.T. Mode Indicator
D. Pulse Indicator
E. Distance
F. Unit of Measure
G. Angle of Incline/Decline
H.
Slope Adjusted Distance
FOR MORE SUPPORT VISIT:
www.CallawayDMD.com/product-support
MANUAL
H
