- Page 1 User Manual UHCE-70XL 4K60 18G HDMI 2.0 Cost-effective Extender Set over CAT5e/CAT6 All Rights Reserved Version: UHCE-70XL_2021V1.7 www.ute.de...
- Page 2 UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till February, 2021.
- Page 3 UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. ⚫ Unpack the equipment carefully and save the original box and packing material for possible future shipment ⚫...
-
Page 4: Table Of Contents
UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 Table of Contents 1. Product Introduction ....................1 1.1 Introduction to 4K60 18G HDMI 2.0 Extender Set UHCE-70XL ......1 1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Panel Description of UHCE-70XL ................2 2.1 4K60 18G HDMI 2.0 Transmitter (UHCE-70XLT) .......... -
Page 5: Product Introduction
1. Product Introduction 1.1 Introduction to 4K60 18G HDMI 2.0 Extender Set UHCE-70XL The 4K60 18G HDMI 2.0 Extender UHCE-70XL is a cost-effective point-to-point extender set for HDMI 2.0 and IR signals; this kit supports 4K/UHD video @60 Hz with 4:4:4 Chroma sampling, as well as HDMI data rates up to 18 Gbps, HDCP 2.2 compliant. -
Page 6: Panel Description Of Uhce-70Xl
UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 2. Panel Description of UHCE-70XL 2.1 4K60 18G HDMI 2.0 Transmitter (UHCE-70XLT) Figure 2-1 UHCE-70XLT (4K60 18G HDMI2.0Transmitter) Name Description RJ45 port to connect the CATx IN port of receiver by CATx cable. -
Page 7: 4K60 18G Hdmi 2.0 Receiver (Uhce-70Xlr)
UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 2.2 4K60 18G HDMI 2.0 Receiver (UHCE-70XLR) Figure 2-2 UHCE-70XLR (4K60 18G HDMI2.0 Receiver) Name Description ① DISPLAY Type-A female HDMI port to connect HDMI display device. RJ45 port to connect the CATx OUT port of transmitter by CATx cable. -
Page 8: System Connection
Use shielded straight-thru CAT5e/ CAT6 cable with TIA/EIA T568B terminations for good transmission effect. 3.2 System Diagram UHCE-70XL The following figure shows a typical application that can be realized with 4K60 18G HDMI 2.0 Cost-effective Extender Set over CAT5e/CAT6 UHCE-70XL: Catx: HDMI: Power:... -
Page 9: Connection Procedure
Note that the CATx cable length should not be less than 15 meters for best video output. 3.4 System Application The 4K60 18G HDMI2.0 Extender Set UHCE-70XL has a good application in various occasions, such as home theater and home entertainment etc. U.T.E. electronic GmbH & Co. KG... -
Page 10: Twisted Pair Cable Connection
UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 3.5 Twisted Pair Cable Connection The twisted pair used in this extender MUST be a straight-through cable. TIA/EIA T568B TIA/EIA T568A Cable color Cable color green white orange white green orange orange white... -
Page 11: Specification
UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 4. Specification Model Transmitter Receiver Spec (UHCE-70XLT) (UHCE-70XLR) Input Input Signal 1 HDMI &1 IR 1 CATx IN & 1 IR, 1 HDMI female 1 RJ-45, Input Connector (19-pin type-A), 1 3.5mm mini jack 1 3.5mm mini jack... -
Page 12: Panel Drawing
UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 5. Panel Drawing Note: Pictures shown in this manual are only for reference. U.T.E. electronic GmbH & Co. KG www.ute.de... -
Page 13: Troubleshooting & Maintenance
UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 6. Troubleshooting & Maintenance ⚫ No image on display: ⚫ Ensure that the display device has been set to the correct input. ⚫ Ensure that the HDMI cables used for both the source/transmitter and the receiver/display are properly connected and are working. -
Page 14: After-Sales Service
7. After-sales Service If there appear some problems when running the 4K60 18G HMDI2.0 Cost-effective Extender Set over CAT5e/CAT6 UHCE-70XL, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. - Page 15 UHCE-70XL: 18G HDMI 2.0 Extender Set over CAT5e/6 5) Technical Support: Email to our after-sales department or make a call, please inform us the following information about your cases. ⚫ Product version and name. ⚫ Detailed failure situations. ⚫ The formation of the cases.
- Page 16 U.T.E. electronic GmbH & Co. KG Tel: +49-2302-282830 Fax: +49-2302-28283-10 Email: info@ute.de Website: www.ute.de...
