- Page 1 User Manual UTE-FOUB30 4-Port USB3.2 Gen1x1 Fiber Optic Extender All Rights Reserved Version: UTE-FOUB30_2022V1.1 www.ute.de...
- Page 2 UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set U.T.E. electronic GmbH & Co. KG www.ute.de...
- Page 3 UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 4 UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
-
Page 5: Table Of Contents
UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set Table of Contents 1. Product Introduction ....................1 1.1. Features ......................1 1.2. Packing List ...................... 2 2. System Connection ....................3 2.1. Usage Precaution ..................... 3 2.2. System Diagram UTE-FOUB30 ................ 3 2.3. -
Page 6: Product Introduction
UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set 1. Product Introduction The 4-Port USB 3.1 Optical Fiber Extender Set UTE-FOUB30 consists of a local unit and a remote unit. UTE-FOUB30 uses optical fiber conversion technology to realize the optical fiber transmission of USB3.2 Gen 1x1/ USB2.0/ USB1.1 signals. -
Page 7: Packing List
UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set 1.2. Packing List 1x Local Unit 1x Remote Unit ⚫ ⚫ 2x TX Mounting Ears with 2 Screws 2x RX Mounting Ears with 2 Screws ⚫ ⚫ 2x Power Adapter (12V DC 1.25A) 1x User Manual ⚫... -
Page 8: System Connection
All devices should be connected before power on. ⚫ 2.2. System Diagram UTE-FOUB30 The following diagrams illustrates typical input and output connections that can be utilized with the USB 3.1 Optical Fiber Extender UTE-FOUB30. 2.3. Application • Machine vision •... -
Page 9: Technical Specification
UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set 3. Technical Specification UTE-FOUB30T UTE-FOUB30R (Local Unit) (Remote Unit) Interfaces (4) USB3.0 type-A female (1) USB3.0 type-B male USB Interface connector connector Fiber Interface (1) LC (1) LC USB Standard USB3.2 Gen1x1 (also known as USB3.1 Gen1 or USB3.0) Supported USB Backward compatible with USB 2.0 and USB 1.1... -
Page 10: Customer Service
UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set 4. Customer Service Any transport costs are borne by the users during the warranty. The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. - Page 11 UTE-FOUB30: 4-Port USB 3.1 Optical Fiber Extender Set 5) Technical Support: Email to our after-sales department or make a call, please inform us the following information about your cases. ⚫ Product version and name. ⚫ Detailed failure situations. ⚫ The formation of the cases.
