- Page 1 User Manual AU-200X eARC and SPDIF Audio Extender Set All Rights Reserved Version: AU-200X_2022V1.0 www.ute.de...
- Page 2 AU-200X: eARC and SPDIF Audio Extender Set Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 AU-200X: eARC and SPDIF Audio Extender Set SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
-
Page 4: Table Of Contents
AU-200X: eARC and SPDIF Audio Extender Set Table of Contents Product Introduction ....................1 1.1. Features ......................1 1.2. Packing List ...................... 1 Panel Description ....................2 2.1. eARC & SPDIF Audio Transmitter ..............2 2.2. eARC & SPDIF Audio Receiver ................ 2 System Connection .................... -
Page 5: Product Introduction
The eARC and SPDIF Audio Extender Set AU-200X includes one Transmitter and one Receiver. AU-200X is designed to transmits HDMI eARC / ARC and optical digital audio signals up to distance of 200m (eARC/ARC signals up to 100m) via CATx cable. -
Page 6: Panel Description
AU-200X: eARC and SPDIF Audio Extender Set 2. Panel Description 2.1. eARC & SPDIF Audio Transmitter ① SPDIF IN: Connect to display for optical audio return. ② eARC IN: Connect to eARC/ARC port on local HDMI display. ③ SPDIF/eARC: Select between eARC/ARC input port between HDMI or Optical input. -
Page 7: System Connection
All devices should be connected before power on. ⚫ 3.2. System Diagram AU-200X The following diagrams illustrates typical input and output connections that can be utilized with the eARC & SPDIF Audio Extender Set AU-200X. U.T.E. electronic GmbH & Co. KG www.ute.de... -
Page 8: Technical Specification
AU-200X: eARC and SPDIF Audio Extender Set 4. Technical Specification AU-200XT AU-200XR (Transmitter) (Receiver) Interfaces (1) Audio-over-CAT/ (1) SPDIF, Input CATx IN (1) eARC IN (1) Toslink, Input Connector (1) RJ45 (1) HDMI (1) Audio-over-CAT/ (1) SPDIF, Output CATx OUT... -
Page 9: Panel Drawing
AU-200X: eARC and SPDIF Audio Extender Set General Operation -0 to +40℃ Temperature Storage Temperature -10 to +50℃ Humidity 10% to 90% relative humidity, non-condensing Input:100V~240V AC; Input:100V~240V AC; Power Supply (External PS) Output:12V DC, 1A Output:12V DC, 1A 2.5W (max) -
Page 10: Customer / After Sales Service
AU-200X: eARC and SPDIF Audio Extender Set 6. Customer / After sales Service Any transport costs are borne by the users during the warranty. The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. - Page 11 AU-200X: eARC and SPDIF Audio Extender Set 5) Technical Support: Email to our after-sales department or make a call, please inform us the following information about your cases. ⚫ Product version and name. ⚫ Detailed failure situations. ⚫ The formation of the cases.
- Page 12 U.T.E. electronic GmbH & Co. KG Tel: +49 (0)2302 / 28283-0 Fax: +49 (0)2302 / 28283-10 Email: info@ute.de Website: www.ute.de...
