- Page 1 User Manual UHKVM-70X 4K HDMI2.0 USB KVM Extender All Rights Reserved Version: UHKVM-70X_2020V1.0 www.ute.de...
- Page 2 UHKVM-70X: 4K HDMI2.0 USB KVM Extender Preface Read this user manual carefully before using the product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local dealer or distributor for maintenance assistance.
- Page 3 UHKVM-70X: 4K HDMI2.0 USB KVM Extender SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
-
Page 4: Table Of Contents
UHKVM-70X: 4K HDMI2.0 USB KVM Extender Table of Contents 1. Introduction ......................... 1 1.1 Product Introduction to UHKVM-70X ..............1 1.2 Features ......................1 1.3 Package List ...................... 2 2. Panel Description ......................3 2.1 4K HDMI2.0 USB KVM Transmitter: UHKVM-70XT........... 3 2.2 4K HDMI20 USB KVM Receiver: UHKVM-70XR .......... -
Page 5: Introduction
UHKVM-70X: 4K HDMI2.0 USB KVM Extender 1. Introduction Thanks for choosing the 4K HDMI 2.0 USB KVM Extender UHKVM-70X which is designed to transmit and extend uncompressed 4K60 (2160p @60Hz) HDMI and USB KVM signals up to 230ft (70m) from transmitter to receiver via a CAT6/ CAT6a/ CAT7 network cable. -
Page 6: Package List
UHKVM-70X: 4K HDMI2.0 USB KVM Extender 1.3 Package List • 1x UHKVM-70XT: 4K HDBaseT HDMI USB KVM Transmitter (local unit) • 1x UHKVM-70XR: 4K HDBaseT HDMI USB KVM Receiver (remote unit) • 1x Power Adapter (12V DC 2A) • 1x USB Cable (Type A to Type A) •... -
Page 7: Panel Description
UHKVM-70X: 4K HDMI2.0 USB KVM Extender 2. Panel Description 2.1 4K HDMI2.0 USB KVM Transmitter: UHKVM-70XT Figure 2-1 Front and Rear Panel of UHKVM-70XT (local unit) Name Description ① Power input Connect with DC 12V/ 2A power adapter (optional) ②... -
Page 8: Hdmi20 Usb Kvm Receiver: Uhkvm-70Xr
UHKVM-70X: 4K HDMI2.0 USB KVM Extender 2.2 4K HDMI20 USB KVM Receiver: UHKVM-70XR Figure 2-2 Front and Rear Panel of UHKVM-70XR (remote unit) Name Description ① Power input Connect with DC 12V/ 2A power adapter ② Power indicator LED indicator turn on when power on... -
Page 9: System Connection
UHKVM-70X: 4K HDMI2.0 USB KVM Extender 3. System Connection 3.1 Usage Precautions 1) Make sure all components and accessories included before installation. 2) System should be installed in a clean environment with proper temperature and humidity. 3) All of the power switches, plugs, sockets, and power cords should be insulated and safe. -
Page 10: Installation Requirements
Note: It is recommended to power from the receiver unit 3.5 System Application The 4K HDMI2.0 USB KVM Extender UHKVM-70X has a good application in various occasions, such as AV transmission in applications of 4K/ HD conference system, 4K/ HD video shooting, 4K/ HD multimedia education system, 4K/ HD digital advertising and signage etc. -
Page 11: Twisted Pair Cable Connection
UHKVM-70X: 4K HDMI2.0 USB KVM Extender 3.6 Twisted Pair Cable Connection The twisted pair/ network cable used in this extender MUST be a straight-through cable comply with the IEEE 568B standard. TIA/EIA T568B Cable color orange white orange green white... -
Page 12: Specification
UHKVM-70X: 4K HDMI2.0 USB KVM Extender 5. Specification Model UHKVM-70XT UHKVM-70XR Spec (Transmitter) (Receiver) Connectors Video Input (1) HDMI Video Output (1) HDMI (1) Type A USB female, (2) Type A USB female USB port [USB cable is included] [for USB KVM]... - Page 13 UHKVM-70X: 4K HDMI2.0 USB KVM Extender Body Properties Dimension (L*W*H) 110 x 87 x 23.5 mm 110 x 87.0 x 32.5 mm Material Iron alloy material Color Black Net Weight 240g 240g U.T.E. electronic GmbH & Co. KG www.ute.de...
-
Page 14: Troubleshooting & Maintenance
UHKVM-70X: 4K HDMI2.0 USB KVM Extender 6. Troubleshooting & Maintenance ⚫ No image output: • Firstly, please check and make sure the power supply is connected well. Then, check and make sure all cables are connected correctly. • Please check and make sure the right HDMI input port of the TV/ screen has been chosen. -
Page 15: Customer/ After-Sales Service
There terms and conditions may be changed without prior notice. If there appear some problems when running the UHKVM-70X please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. - Page 16 U.T.E. electronic GmbH & Co. KG Tel: +49-2302-28283-0 Fax: +49-2302-28283-10 Email: info@ute.de Website: www.ute.de...
