- Page 1 User Manual HD-383-V4 HDMI over IP Extender Set All Rights Reserved Version: HD-383-V4_2022V1.0 www.ute.de...
- Page 2 HD-383-V4: HDMI over IP Extender Set with IR passback Preface Read this user manual carefully before using the product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local dealer or distributor for maintenance assistance.
- Page 3 HD-383-V4: HDMI over IP Extender Set with IR passback SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
-
Page 4: Table Of Contents
HD-383-V4: HDMI over IP Extender Set with IR passback Table of Contents 1. Introduction ......................... 1 1.1 Product Introduction to HD-383-V4 ..............1 1.2 Package List ...................... 1 2. Panel Description ......................2 2.1 HDMI Extender TX (Sender) ................2 2.2 HDMI Extender RX (Receiver) ................ -
Page 5: Introduction
1. Introduction 1.1 Product Introduction to HD-383-V4 Thanks for choosing the HDMI over IP Extender Set HD-383-V4 which is designed to transmit HDMI Video/ Audio up to 120m (394ft) with single network cable. The extender set HD-383-V4 includes a transmitter unit and a receiver unit and supports IR signal transmission (IR passback), to control media playback of the signal source device at the display location. -
Page 6: Panel Description
HD-383-V4: HDMI over IP Extender Set with IR passback 2. Panel Description 2.1 HDMI Extender TX (Sender) Figure 2-1 HD-383T-V4 (HDMI Transmitter) Name Reset ① HDMI signal input ② IR signal output to connect with IR blaster extension cable ③... -
Page 7: Hdmi Extender Rx (Receiver)
HD-383-V4: HDMI over IP Extender Set with IR passback 2.2 HDMI Extender RX (Receiver) Figure 2-2 HD-383R-V4 (HDMI Receiver) Name Reset ⑨ HDMI signal output ⑩ IR signal output to connect with IR receiver extension cable ⑪ Power input (DC 5V) ⑫... -
Page 8: System Connection
HD-383-V4: HDMI over IP Extender Set with IR passback 3. System Connection 3.1 Usage Precautions 1) Make sure all components and accessories included before installation. 2) System should be installed in a clean environment with proper temperature and humidity. 3) All of the power switches, plugs, sockets, and power cords should be insulated and safe. -
Page 9: Connection & Installation
HD-383-V4: HDMI over IP Extender Set with IR passback 4. Connection & Installation 4.1 Twisted Pair Cable Connection The twisted pair/ network cable used in this extender MUST be a straight-through cable comply with the IEEE 568B standard. TIA/EIA T568B... -
Page 10: Cascade Connection
HD-383-V4: HDMI over IP Extender Set with IR passback Cascade Connection 4.2.2 By using network switches to realize unlimited extension. One-to-many Connection 4.2.3 By using network router/ switch, one sender to several receivers, realize extender & splitter function Note: Gigabit (1000Mbps) switcher is recommended in LAN transmission U.T.E. -
Page 11: Ir User Guide
HD-383-V4: HDMI over IP Extender Set with IR passback 4.3 IR User Guide 1) IR blaster extension cable should plug-in the IR-out port of TX (Sender) of HDMI extender, and the IR receiver extension cable should plug-in the IR-in port of the RX (Receiver) of HDMI extender. -
Page 12: Faq
HD-383-V4: HDMI over IP Extender Set with IR passback 6. FAQ TV display “Waiting for connection”? Please check if the power supply of TX (Sender) and switcher (if used) is connected, and make sure connecting cable is firmly; TV display “Please check the TX input signal”? 1) please check if there is a HDMI signal input of TX;... -
Page 13: Customer/ After-Sales Service
There terms and conditions may be changed without prior notice. If there appear some problems when running the HD-383-V4 please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. - Page 14 HD-383-V4: HDMI over IP Extender Set with IR passback U.T.E. electronic GmbH & Co. KG www.ute.de...
- Page 15 HD-383-V4: HDMI over IP Extender Set with IR passback U.T.E. electronic GmbH & Co. KG www.ute.de...
- Page 16 U.T.E. electronic GmbH & Co. KG Tel: +49-2302-28283-0 Fax: +49-2302-28283-10 Email: info@ute.de Website: www.ute.de...
