Noaton DF 4214 HEPA Instructions For Use Manual

Dehumidifier and air purifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTIONS FOR USE
Noaton DF 4214 H EP A
Dehumidifier and air purifier

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DF 4214 HEPA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Noaton DF 4214 HEPA

Summary of Contents for Noaton DF 4214 HEPA

  • Page 1 INSTRUCTIONS FOR USE Noaton DF 4214 H EP A Dehumidifier and air purifier...
  • Page 2 Read the instructions for use. Before any use, read the corresponding section in this User Guide. A service manual is available on request for certified workshops. This product must not be disposed of with other household waste at the end of its useful life, but must be taken to a collection point designated for the recycling of electrical equipment.

  • Page 3: Table Of Contents

    CONTENTS 1. Safety instructions ..........................4 2. Warning in relation to R290 refrigerant .................5 3. Instrument features...........................6 4. Parameters..........................7 5. Instrument description........................9 6. Before starting........................11 6.1. Filter installation......................11 6.2. Correct placement........................11 7. Continuous condensate drain .......................12 8. Controls and functions ........................13 8.1.

  • Page 4: Safety Instructions

    1. Safety instructions Before using the dehumidifier, read the instructions for use carefully, especially the following safety instructions and warnings in relation to R290 refrigerant. Install the unit on a level and solid floor to reduce vibration or noise. NOTE: After shipping, allow the unit to stand upright for at least 6 hours before starting. This procedure will protect the compressor and extend the life of this unit.
  • Page 5 be carried out by a specially qualified person.

  • Page 6: Warning In Relation To R290 Refrigerant

    2. Warning in relation to R290 refrigerant This equipment is designed to use only R290 (propane) refrigerant, which is hermetically sealed under pressure in the refrigeration circuit. Repairs to this equipment may only be carried out by a specially trained service technician in accordance with national legislation relating to flammable substances! The service manual is available on request.

  • Page 7: Instrument Features

    3. Instrument features Powerful dehumidification Using compressor technology, this dehumidifier removes excessive humidity in the room. Compact and portable design The simple design of the dehumidifier and its low weight guarantee very easy and effortless handling. Two dehumidification modes Two types of dehumidification mode are available for the user: manual, where the user can choose the target humidity, and continuous dehumidification (drying of laundry).

  • Page 8: Parameters

    4. Parameters PARAMETER VALUE Power supply220 V - 240 V / 50 Hz 210 W (35℃,80 %RV) Energy consumption 155 W (27℃, 60 %RV) Rated current 0.9 A (30℃, 80 %RV) 14 l/day (35℃, 90%RV) Dehumidification 12 l /day (30℃,80 %RV) capacity 7 l/day (27℃,60 %RV) Max.
  • Page 9 PARAMETER VALUE Automatic shutdown when the tank is full Automatic humidity maintenance Memory during power failure Timer 0 - 24 hours delayed start, delayed shutdown) Instrument size 309 x 229 x 478 mm Package size 350 x 270 x 505 mm Instrument weight 11 kg Weight including packaging...

  • Page 10: Instrument Description

    5. Instrument description Components Control panel...
  • Page 11 Components č. description Air outlet Front cover Control panel Handle Water tank Wheels Top cap Air intake grille with pre-filter Outlet for hose outlet Back cover Power cable Control panel Descrip tion On/Off button Timer Up and down button Fan speeds / Child lock Mode selector button / Night mode Air cleaning indicator light Laundry drying mode indicator light...

  • Page 12: Before Starting

    6. Before starting After shipping, allow the unit to stand upright for at least 6 hours before starting. This procedure will protect the compressor and extend the life of the unit. Failure to follow this procedure may result in reduced performance, damage to the cooling circuit and void the warranty! 6.1.

  • Page 13: Continuous Condensate Drain

    • Place the dehumidifier upright on a stable and level floor. • Make sure the unit is positioned in the room so that the minimum distances as shown in the figure above are maintained. • The input voltage parameters must correspond to the technical label on the device, the electrical socket must be earthed.

  • Page 14: Controls And Functions

    8. Controls and functions 8.1. Switching the device on and off Plug the power cord into the mains and press the power button (12). An audible signal will sound and the unit will start in default mode, i.e. manual mode is selected and set to continuous dehumidification with the fan on the highest speed, the on/off indicator light (25) will be lit.

  • Page 15: Fan Speed Setting

    Notes: a. The automatic switch-off setting will be cancelled if the timer button (13) is pressed twice within 3 seconds. b. The automatic shutdown setting will be cancelled if the device is switched off and restarted. c. The auto-start setting will be cancelled if the device is started manually. 8.3.

  • Page 16: Air Purification Mode

    8.4.2. Air cleaning mode Press the mode selector button (16) until the air cleaning light (17) comes on. The compressor will turn off, the unit will stop dehumidifying and the fan will switch to a high speed that can be changed.

  • Page 17: Night Mode

    8.4.4. Night mode Press and hold the mode selector button (16) for 2 seconds and the unit will switch to night mode. All lights and display will go out and the fan speed will switch to low. Note: If the reservoir fills in this mode, the full reservoir light (24) will illuminate, but the unit will not beep.

  • Page 18: Low Temperature Defrost Mode

    8.6. Low temperature defrost mode If the ambient temperature is low (generally between approximately 5 and 16 °C), the appliance automatically switches to defrost mode as required and the corresponding indicator light (22) illuminates. In this mode, the appliance does not dehumidify 8.7.

  • Page 19: Memory Functions

    8.8. Memory functions a. When the power cord is disconnected from the mains or when the power fails and the power is reconnected, the dehumidifier will operate in pre-shutdown mode. The timer setting will be maintained. b. Press the on/off button (12) to switch off the dehumidifier and then switch it on again by pressing the same button.

  • Page 20: Hepa Filter Cleaning

    9.3. HEPA filter cleaning You can partially extend the life of the HEPA filter by vacuuming its surface, but the particles deposited inside the filter can no longer be removed. Do not use water, compressed air from a compressor or any method other than a normal vacuum cleaner to clean this filter.
  • Page 21 The compressor is stopped, the fan is running at low speed. If the Inlet air is too cold Slowly temperature rises above 0 °C (<0 °C) flashing L4 after 10 minutes, the unit will run normally...

  • Page 22: Troubleshooting

    12. Troubleshooting Before you contact a service professional, read this list. It may save you costs and time. This list includes common cases that are not the result of a defect in workmanship or materials. PROBLEM POSSIBLE CAUSE SOLUTION Power cable not connected Plug the cable into the socket The reservoir is full Empty the reservoir...
  • Page 23 surface...

  • Page 24: Disposal

    13. Disposal The crossed-out bin icon on electrical and electronic waste indicates that the equipment must not be disposed of with household waste at the end of its life. This waste must be disposed of in accordance with the applicable local legislation by taking it to selected e-waste collection points near your home.
