DIGITAL YACHT veKonvert Gateway Installation And Instruction Manual

Table of Contents

Download this manual

veKonvert

GATEWAY

Table of Contents

Need help?

Do you have a question about the veKonvert Gateway and is the answer not in the manual?

Page 1 veKonvert GATEWAY...
Page 2 1. Introduction Congratulations on the purchase of your veKonvert Gateway. This product is designed to allow Victron devices to send data to an NMEA2000 network. Many Victron devices have a VE.Direct interface that allows them to communicate with other Victron devices. VE.Direct is a serial protocol where data “Producers” like SmartShunts, Battery Monitors (BMV) and Solar Controllers (MPPT) send data to data “Consumers”...
Page 3 Mounting The veKonvert Gateway has two slotted 4mm Diameter fixing holes. Use suitable fixings (not supplied) to fix the converter to a flat surface – using the dimensions and details shown in the drawing below. Note that the unit may be installed in any orientation.
Page 4 Multiple SmartShunts/Battery Monitors, then each veKonvert will need to have a different Device Instance To change the DIP switches, open the veKonvert Gateway by unscrewing the two cross head screws in the base of the unit. Then set the DIP switches to create a four bit binary number as follows…...
