- Page 1 Installation & Quick Start Guide Aqua PC Range – AquaNav PC Version QUICK START AquaNav PC VR1.02...
-
Page 2: Before You Start
AquaNav PC Quick Start Guide DIGITAL YACHT LTD 1. Introduction Congratulations on the purchase of your AquaNav PC. It is recommended that your new computer is installed by a professional installer. Do not disconnect the White wire from the Red on the main power/data cable until you have read and understood the Remote Switch operation (Installation Step 3+4) explained in this Quick Start Guide. - Page 3 AquaNav PC Quick Start Guide DIGITAL YACHT LTD Installation Step 2 The AquaNav PC is supplied with four mounting brackets which are screwed (wrong way round) to the base of the AquaNav PC for transit. Unscrew the brackets, reverse them and screw them back in place. Use suitable fixings (not supplied) to fix the AquaNav PC to a flat surface –...
- Page 4 AquaNav PC Quick Start Guide DIGITAL YACHT LTD Installation Step 3 On the rear of the AquaNav PC are two black cables. The top cable has nine wires and is the Power/Data cable. Connect the Red (+) and Black (-) wires in the Power/Data cable to the ship’s 12v or 24v supply.
- Page 5 AquaNav PC Quick Start Guide DIGITAL YACHT LTD Installation Step 5 The connections on the rear of the AquaNav PC are as follows; The wires in the nine core Power/IO are as follows; Power + (12v or 24v) Power –...
- Page 6 AquaNav PC Quick Start Guide DIGITAL YACHT LTD To connect NMEA devices to the AquaNav PC you can connect them directly to the two COM port wires in the Power/IO cable. A couple of typical examples are shown below;...
