- Page 1 Installation and User Manual ProAero™/ProAero™ UL Air Extraction System DOC-01003 Rev. F...
- Page 2 Stratasys. This document may be printed for internal use only. All copies shall contain a full copy of this copyright notice.
-
Page 3: Table Of Contents
Maintenance ....................9 Inspecting the System ......................10 Cleaning the System ......................10 Replacing the Filters ......................10 Disposing of the Filters......................13 System Specifications.................. 13 Dimensions ......................... 14 Filter Information ......................... 14 © Copyright 2023 Stratasys. All rights reserved. Page iii... -
Page 4: Overview
Overview ProAero in this document refers to both ProAero and ProAero UL. Figure 1: ProAero front inlet Cover Cover clip Control panel Figure 2: ProAero rear outlet Control cable 48VDC Max input Power switch 100-240 VAC Power connector Fuse compartment ©... -
Page 5: Safety
1. Always disconnect the system from the main power supply before servicing. 2. Use this system only as described in this manual. 3. Connect the system to a properly grounded outlet. © Copyright 2023 Stratasys. All rights reserved. Page 2... -
Page 6: Fire Safety
However, it is the responsibility of the user to verify the media and filter type are suitable for the particular application where the air extraction system is being used. © Copyright 2023 Stratasys. All rights reserved. Page 3... -
Page 7: Warning And Information Labels
If you intend to vent the air from the system directly into the room, place the system at least 50 cm (19.5 in.) from another object on the side of the air outlet to ensure adequate airflow. © Copyright 2023 Stratasys. All rights reserved. Page 4... - Page 8 3. Verify that the filter is positioned correctly before replacing the cover and securing the clips. Figure 3: Securing the cover Cover Pre-filter Combined filter Caution: Do not cover the exhaust outlets, as this restricts the airflow and causes overheating. © Copyright 2023 Stratasys. All rights reserved. Page 5...
-
Page 9: Installation
Check the integrity of the electrical power cable. If the power cable is damaged, do not connect the extraction system to the main power supply with that power cable. The power cable should only be replaced by a Stratasys engineer, as an electrical safety test might be required after replacement. -
Page 10: Connecting To The J3/J5 Series 3D Printer
2. Connect the exhaust duct to the adapter on the printer and secure the duct to the adapter. 3. Connect and secure the other end of the exhaust duct to the ProAero. The vent out of the printing area should be as close as possible to the printing area without interfering with the 3D printing process, to ensure effective fume extraction. -
Page 11: Connecting To The Origin One 3D Printer
4. Connect the exhaust duct to the adapter on the top of the printer, and secure the duct to the adapter. 5. Connect and secure the other end of the exhaust duct to the ProAero. The vent out of the printing area should be as close as possible to the printing area without interfering with the 3D printing process, to ensure effective fume extraction. -
Page 12: Operation
When first installing the system, set the airflow on the second LED from the bottom. Maintenance User maintenance is limited to cleaning the system and filter replacement. Only Stratasys technicians are authorized to perform component testing and replacement. Warning: Personal Injury Hazard... -
Page 13: Inspecting The System
To re-order, refer to the filter number printed on the filter installed in your extraction system. The ProAero contains a pre-filter pad and a combined filter. Caution: To prevent overheating, do not use the system with a blocked filter, or with dust obstruction of inlets/outlets. - Page 14 3. Lift the pre-filter pad out from the top of the combined filter and replace with a new pad. It is recommend to place the used filters in a sealed bag before discarding. © Copyright 2023 Stratasys. All rights reserved. Page 11...
- Page 15 3. Open the clips on the sides of the system and remove the cover. 4. Lift the filter out of the system. It is recommend to place the used filters in a sealed bag before discarding. 5. Insert the new filter into position. © Copyright 2023 Stratasys. All rights reserved. Page 12...
-
Page 16: Disposing Of The Filters
Operating temperature range: +5 °C to + 40 °C (41 °F to 104 °F) • Operating humidity range: • Max 80% Relative Humidity up to 31 °C (88 °F) • Max 50% Relative Humidity at 40 °C (104 °F) © Copyright 2023 Stratasys. All rights reserved. Page 13... -
Page 17: Dimensions
Width 11.1 Filter Information Filter Type Construction Efficiency Pre-Filter Pad Glass Fiber F7 (96% @ 2 microns) Combined Filter Maxipleat Construction 99.997% @ 0.3 microns HEPA with Webbing Spacers Carbon Granules © Copyright 2023 Stratasys. All rights reserved. Page 14... - Page 18 _____ c-support@stratasys.com Copyright © 2023 Stratasys Ltd. All rights reserved. DOC-01003 Rev. F THE 3D PRINTING SOLUTIONS COMPANY...
