- Page 1 Installation and User Manual ProAero™ Air Extraction System DOC-01003 Rev. D...
- Page 2 Stratasys. This document may be printed for internal use only. All copies shall contain a full copy of this copyright notice.
-
Page 3: Table Of Contents
Maintenance ....................9 Inspecting the System ......................9 Cleaning the System ......................9 Replacing the Filters ......................9 Disposing of the Filters......................12 System Specifications.................. 12 Dimensions ......................... 12 Filter Information ......................... 13 © Copyright 2020 Stratasys. All rights reserved. Page iii... -
Page 4: Overview
Overview Overview Figure 1: Air extraction system (front) inlet Cover Cover clip Indicators controls Figure 2: Control panel Filter change indicator Motor speed adjustment © Copyright 2020 Stratasys. All rights reserved. Page 1... - Page 5 The air then exits through the opening under the system. When the rear outlet is in use, cover the opening under the system with the plate. © Copyright 2020 Stratasys. All rights reserved. Page 2...
-
Page 6: Safety
1. Always disconnect the system from the main power supply before servicing. 2. Use this system only as described in this manual. 3. Connect the system to a properly grounded outlet. © Copyright 2020 Stratasys. All rights reserved. Page 3... -
Page 7: Fire Safety
However, it is the responsibility of the user to verify the media and filter type are suitable for the particular application where the air extraction system is being used. © Copyright 2020 Stratasys. All rights reserved. Page 4... -
Page 8: Warning And Information Labels
If you intend to vent the air from the system directly into the room, place the system at least 500mm (19.5 in.) from another object on the side of the air outlet to ensure adequate airflow. © Copyright 2020 Stratasys. All rights reserved. Page 5... - Page 9 2. Verify that the filter is positioned correctly before replacing the cover and securing the clips. Figure 4: Securing the cover Cover Pre-filter Combined filter Caution: Do not cover the exhaust outlets, as this restricts the airflow and causes overheating. © Copyright 2020 Stratasys. All rights reserved. Page 6...
-
Page 10: Installation
Check the integrity of the electrical power cable. If the power cable is damaged, do not connect the extraction system to the main power supply. The power cable should only be replaced by a Stratasys engineer, as an electrical safety test might be required after replacement. -
Page 11: Operation
LEDs. As you increase the airflow, more blue LEDs light. Figure 6: Control panel Filter change Motor speed indicator adjustment When first installing the system, set the airflow on the second LED from the bottom. © Copyright 2020 Stratasys. All rights reserved. Page 8... -
Page 12: Maintenance
Maintenance Inspecting the System Maintenance User maintenance is limited to cleaning the system and filter replacement. Only Stratasys technicians are authorized to perform component testing and replacement. Warning: Personal Injury Hazard Unauthorized work or the use of unauthorized replacement filters may result in a potentially dangerous situation and/or damage to the extraction system, and will void the manufacturer’s warranty. - Page 13 3. Lift the pre-filter pad out from the top of the combined filter and replace with a new pad. It is recommend to place the used filters in a sealed bag before discarding. © Copyright 2020 Stratasys. All rights reserved. Page 10...
- Page 14 2. Open the clips on the sides of the system and remove the cover. 3. Lift the filter out of the system. It is recommend to place the used filters in a sealed bag before discarding. © Copyright 2020 Stratasys. All rights reserved. Page 11...
-
Page 15: Disposing Of The Filters
• Maximum altitude: 2000 m (6561 ft.) • Allowable voltage input: +/-10% • Control cable: 22-48 VDC input, 20 mA Dimensions Metric (mm) Imperial (inches) Height 16.3 Depth 11.7 Width 11.1 © Copyright 2020 Stratasys. All rights reserved. Page 12... -
Page 16: Filter Information
Filter Information Filter Information Filter Type Construction Efficiency Pre-Filter Pad Glass Fiber F7 (96% @ 2 microns) Combined Filter Maxipleat Construction 99.997% @ 0.3 microns HEPA with Webbing Spacers Carbon Granules © Copyright 2020 Stratasys. All rights reserved. Page 13... - Page 17 _____ c-support@stratasys.com Copyright © 2020 Stratasys Ltd. All rights reserved. DOC-01003 Rev. D THE 3D PRINTING SOLUTIONS COMPANY...
