- Page 1 You can also download the latest manual from official website. MIMAKI ENGINEERING CO., LTD. https://mimaki.com/ D203677-10 Original instructions...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction .................. 3 To Ensure Safe Use ............... 5 Symbols .................... 5 Usage Precautions ................ 6 Prohibited Dangerous Actions ............ 10 Usage Restrictions................ 12 Usage Restrictions................ 12 Operator Restrictions................ 12 Area Restrictions ................ 12 Ink and Other Liquid Handling Precautions ........ 14 Installation Precautions.............. -
Page 3: Introduction
ATTRIBUTABLE TO MATERIALS CREATED WHILE USING THIS MACHINE. • USING THIS MACHINE IN CONJUNCTION WITH DEVICES OTHER THAN THOSE RECOMMENDED BY MIMAKI ENGINEERING MAY RESULT IN FIRE OR ACCIDENTS. SUCH INCIDENTS ARE NOT COVERED BY THE PRODUCT WARRANTY. MIMAKI ENGINEERING REJECTS ALL LIABILITY FOR DAMAGES, DIRECT OR INDIRECT, ARISING FROM SUCH INCIDENTS. - Page 4 • Use only the cables recommended by Mimaki Engineering when connecting to the product. Use of other cables may cause the product to exceed the restrictions stipulated by FCC regulations. To maintain compliance with FCC regulations, use the cables recommended by Mimaki...
-
Page 5: To Ensure Safe Use
To Ensure Safe Use Symbols In this manual, the symbols indicate and explain precautions. Make sure you fully understand the meaning of each symbol and use the machine safely and correctly. Explanation Warning Indicates a potential hazard that may result in death or serious injury if handled improperly or if instructions are disregarded. -
Page 6: Usage Precautions
Usage Precautions l In the event of abnormal conditions • In the event of abnormal conditions such as smoke or unusual odor, turn off the main power immediately and turn off the breaker. Continuing to use the machine under these conditions may result in failure, electric shock, or fire. - Page 7 l Power supply precautions • Do not attempt to modify the cable. Avoid damaging the cable. Avoid placing heavy objects on the power cable or pulling on or exposing the cable to heat. Doing so may damage the cable, resulting in electric shock or fire. •...
- Page 8 • Use at low temperature may cause the vacuum unit to generate a high-pitched noise. This does not indicate a failure. l Do not stand or sit on the machine. • Never stand or sit on the platen. Disregarding this precaution may impair the precision of the platen surface and affect print quality.
- Page 9 l About the touch panel • Do not press, rub, or push the touch panel with excessive force. • Do not tap the touch panel with a ball-point pen or other hard metal object. • Do not touch the black outer frame of the screen. •...
-
Page 10: Prohibited Dangerous Actions
Prohibited Dangerous Actions Never perform any of the following dangerous actions while the power is turned on. Disregarding these precautions may result in serious injury (crushing or severing) if the carriage moves, for example during periodic maintenance. l Keep face, hands, and body away from carriage •... - Page 11 l Keep face, hands, body, and other objects away from cableveyor • Keep your face, hands, and body away from the Y cableveyor, and do not place objects on top of it. l Keep face, hands, and body away from underneath platen during operation •...
-
Page 12: Usage Restrictions
Usage Restrictions Usage Restrictions • The machine includes fast-moving and high temperature parts, which present extreme hazards. The machine must be used only by persons that are fully aware of these potential dangers. Operator Restrictions • The machine must be operated only by persons that have received our safety training or who have been trained by such trained personnel. - Page 13 • If a safety fence is used to restrict the area, this should comply with the EN ISO 13857 standard. • If the machine is installed in a dedicated room, locks and safety Interlocks should be provided on the doors to the room, and ultimately a risk assessment should be conducted for the installation before use.
-
Page 14: Ink And Other Liquid Handling Precautions
Thoroughly read them and make sure you understand the contents. • Be sure to read the safety data sheet (SDS) before use. https://mimaki.com/supply/sds/ • Pay close attention to ventilation and be sure to wear safety glasses, gloves, and a mask when handling ink, maintenance liquid, waste ink, or other solutions used with the machine. -
Page 15: Installation Precautions
Installation Precautions • Do not install the machine in locations where naked flames are used. • Do not place plant pots, cups, containers of cosmetics, chemicals, or water, or small metal objects on top of the machine. There is a risk of failure, electric shock, or fire if liquids or other items fall inside the machine. -
Page 16: Installation Space
Installation Space Provide the following space around the machine to allow safe and proper replacement of ink and media: Item Tiger600-1800TS At least 8,300 mm (5,300 mm) Width At least 5,800 mm (2,800 mm) Depth (1,900 mm) Height Weight 1,620 kg *1. -
Page 17: Adjuster Feet
Adjuster Feet Do not attempt to adjust the adjuster feet yourself. Doing so may prevent the machine from operating correctly. If you have any queries, contact your local distributor, our sales office, or service center. [Top view] Large adjuster feet Small adjuster feet When Relocating This Machine Contact your local dealer or our service office. -
Page 18: Emergency Stop Switches And Light Curtain
Emergency Stop Switches and Light Curtain The machine is equipped with emergency stop switches and a light curtain to ensure safety during use. The light curtain stops the machine when a person or object is detected. • Check to confirm that the emergency stop switches and light curtain operate correctly before starting operation. -
Page 19: Warning Labels
Warning labels Make sure you fully understand the details indicated on the various warning labels. If any of the warning labels becomes dirty and illegible or peel off, contact your local dealer or our service office to request new warning labels. - Page 20 Order code Label Details M903239 Indicates hot parts. M903281 Note when connecting the power supply cable. M903330 Wear safety glasses and gloves while working. M905624 Caution regarding current leakage. M906115 Caution regarding moving parts. M906222 Caution overhead. M907764 Do not climb on top CAUTION ATTENTION DO NOT STEP ON TOP...
- Page 21 Order code Label Details M912054 Caution regarding entrapment. M918531 Caution when lifting heavy objects.
-
Page 22: Agreement Confirmation
Customer's copy Agreement Confirmation I hereby confirm that I have received appropriate safety training from a MIMAKI ENGINEERING CO., LTD. service engineer or a retail company in accordance with "Safety Precautions" in the machine manual. I also hereby confirm that this machine will be used only by persons that have received safety training or who have been trained by such trained personnel. - Page 23 Safety Precautions July, 2023 MIMAKI ENGINEERING CO.,LTD. 2182-3 Shigeno-otsu, Tomi-shi, Nagano 389-0512 JAPAN D203677-10-18072023...
