Nauticam N100 X1855-Z Instruction Manual

Zoom gear for fujifilm fujinon xf18-55f2.8-4.0

Current as of 1/16/2023

INSTRUCTION MANUAL

For N100 X1855-Z Zoom Gear for

Fujifilm FUJINON XF18-55F2.8-4.0

PN# 36474

FORWORD

Thank you for your purchase of a NAUTICAM

product.

At NAUTICAM, we pride ourselves in the ability to

recognize the requirements of professional as well

as amateur underwater photographers and fulfill

them through the innovative designs of our

products. We strive to achieve a high level of

user-friendliness by allowing stress-free

installation and easy operation of all important

functions of the camera.

Each product is individually inspected and water

pressure tested to ensure optimum quality.

Please read this manual carefully before using the

product, this will maximize its performance as well

as its lifetime.

Table of Contents

Do you have a question about the N100 X1855-Z and is the answer not in the manual?

Page 1 PN# 36474 FORWORD Thank you for your purchase of a NAUTICAM product. At NAUTICAM, we pride ourselves in the ability to recognize the requirements of professional as well as amateur underwater photographers and fulfill them through the innovative designs of our products.
Page 2 NAUTICAM does not hold responsibility for damage, of any nature, to any equipment used with and/or placed within our products. NAUTICAM accepts no liability for any loss of captured images or the inability to capture images even if it is due to the malfunctioning of our products.
Page 3 IDENTIFICATION OF PARTS Plastic C-ring X1855-Z Zoom Gear Spare Rubber grips...
Page 4 MOUNT THE GEAR ON A LENS 1. Insert the plastic C-ring as shown and place it over the lens. 2 Insert the X1855-Z Zoom Gear on the plastic C-ring until it reaches the flange of the plastic C-ring. 3. To remove the X1855-Z Zoom Gear, reverse the above steps.
Page 5 CONTROL THE GEAR 1. The X1855-Z Zoom Gear can be controlled by zoom/focus knob of the housing. After mount the camera and lens (with gear installed) on the housing, confirm that the zoom/focus knob operates correctly.
Page 6 SPECIFICATIONS #36474 N100 X1855-Z Zoom Gear for Fujifilm FUJINON XF18-55F2.8-4.0 Dimensions: DIA87.0mm ×41.9mm Type: Zoom gear Fujifilm FUJINON XF18- Compatible lens: 55F2.8-4.0 Remark: Nauticam supports only e-manuals. Please download corresponding product manuals on google drive https://bit.ly/Nauticammanual, or contact us for e-...
