Extension Unit
WJ-HXE410 Series
Model No.
For professional use only
WJ-HXE410 Series refer to WJ-HXE410, WJ-HXE410G and WJ-HXE410GV.
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
Advertisement
Table of Contents
Related Manuals for i-PRO WJ-HXE400 Series
Summary of Contents for i-PRO WJ-HXE400 Series
- Page 1 Important Information Extension Unit WJ-HXE410 Series Model No. For professional use only WJ-HXE410 Series refer to WJ-HXE410, WJ-HXE410G and WJ-HXE410GV. Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. The model number is abbreviated in some descriptions in this manual.
-
Page 2: Important Safety Information
Open the fuse cover with a screwdriver and replace the fuse and close or attach the fuse cover. For U.S.A. Supplier's Declaration of Conformity Figure A Figure B Trade Name: i-PRO Model No. : WJ-HXE410 Responsible Party: i-PRO Americas Inc. 8550 Fallbrook Drive, Suite 200 Houston, Texas 77064 Support Contact: 1-800-513-5417... -
Page 3: Table Of Contents
Contents Important Safety Information ....................2 Introduction ..........................4 Preface ...................................... 4 Disclaimer of warranty ................................4 Precautions ..........................5 Major operating controls and their functions ............... 8 Front view ....................................8 Inside the front cover ................................10 Rear view ....................................11 HDD unit .......................... -
Page 4: Introduction
Make sure to connect a corresponding recorder to the unit because the HDD units cannot be set with the unit only. Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW: (1) ANY LOSS OR DAMAGE, INCLUDING WITHOUT LIMITATION, DIRECT OR INDIRECT, SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR RELATING TO THE PRODUCT;... -
Page 5: Precautions
Precautions Refer installation work to the dealer. Grounding Installation work requires technique and experiences. Failure Use this product after confirming that grounding is properly to observe this may cause fire, electric shock, injury, or installed. damage to the product. If grounding is not installed properly, it may cause ground •... - Page 6 Precautions (continued) Precautions for use Power source Hard disk drive (HDD) The input power source for this product is 100 V - 240 V AC • Hard disk drives are precision devices. Handle them with 50 Hz/ 60 Hz. care. It is possible to damage them if they are moved Do not connect to the outlet that provides the power to while their motors are still running.
- Page 7 Disclaimer of warranty on recoded data i-PRO Co., Ltd. assumes no responsibility or liability, directly or indirectly, for failure of recording or editing including loss of data due to any reason or cause which does not exclude repair or maintenance of this product regardless whether the subject is hard disk or other parts.
-
Page 8: Major Operating Controls And Their Functions
Major operating controls and their functions Front view ➀ ➁ ➂ ➃ ➄ ⑥ ⑦ ➀ Error indicator [ERROR] ➂ HDD access indicator (1~9) Blinks when an error that can become a problem for the It transmits the HDD status indicator and the HDD extension unit to run the system occurs. - Page 9 Major operating controls and their functions (continued) ➅ Set button [Set] Use this button to initialize the settings of the unit (default) in the following directions. ① Turn on the unit while pressing the set button. ② P ress the set button again to initialize the settings after "INITIALIZE ACCEPT [SET]"...
-
Page 10: Inside The Front Cover
Major operating controls and their functions (continued) Inside the front cover The following illustration shows that 9 HDD units are installed with the "HDD unit holding brackets" removed. ➀ ➁ ➂ ➃ ➄ ➀ HDD units [Option] Lights red: Indicates that the respective hard disk drive Only the hard disk drive encased in the dedicated hard is faulty (which can be recovered by replacing the hard disk drive) -
Page 11: Rear View
Major operating controls and their functions (continued) Rear view ⑧ ➀ ⑦ ➁ ➂ ➃ ➄ ⑥ ① Security wire hole How to fix the power cord Mount the lock device for the anti-theft security wire. Fix the power cord firmly at 15 cm to 20 cm {5-7/8 to 7-7/8 inches} from the plug with the included power cord clamp ②... -
Page 12: Hdd Unit
HDD unit Handle the HDD units To install a hard disk drive in the recorder, it is necessary to assemble an HDD unit (encase the hard disk drive in the HDD canister). The HDD unit is designed to easily install/remove the hard disk drive in/from the recorder. Contact your dealer about purchasing, installing, and replacing the hard disk drives. -
Page 13: When You Transport The Recorder
HDD unit (continued) How to attach the HDD unit holding bracket Angle ① ① Insert the HDD unit holding bracket into the angle hole. ② HDD unit holding bracket ② Fix the HDD unit holding bracket with a screw while sliding it to the left. -
Page 14: Install The Hdd Unit In Extension Unit
HDD unit (continued) Install the HDD unit in extension unit Refer to the Installation Guide for installing the HDD unit to this recorder. Remove the HDD units from extension unit When removing the HDD unit, it is necessary to perform the removal process in advance. When replacing the HDD unit, it is necessary to perform the removal process/the link process. -
Page 15: Specifications
Specifications • General Power source: 100 V - 240 V AC 50 Hz/ 60 Hz Power consumption: 92 W (98 VA) Ambient operating temperature: Main body: 0 °C - +45 °C {32 °F - 113 °F} Ambient operating humidity: 5 % to 90 % (non condensing) Maximum operating altitude: 2000 m {6562 feet} above sea level Recording compression method:... - Page 16 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB Amsterdam, Netherlands Tokyo, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2023 L1023-1064 PGQP3709YA...
