Installation Guide
Extension Unit
WJ-HXE410 Series
Model No.
For professional use only
WJ-HXE410 Series refer to WJ-HXE410, WJ-HXE410G and WJ-HXE410GV.
The Operating Instructions and Important Information is on our support website
(https://i-pro.com/global/en/surveillance/documentation_database).
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WJ-HXE410 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for i-PRO WJ-HXE410 Series

Summary of Contents for i-PRO WJ-HXE410 Series

  • Page 1 Extension Unit WJ-HXE410 Series Model No. For professional use only WJ-HXE410 Series refer to WJ-HXE410, WJ-HXE410G and WJ-HXE410GV. The Operating Instructions and Important Information is on our support website (https://i-pro.com/global/en/surveillance/documentation_database). Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.

  • Page 2: Table Of Contents

    Contents Introduction ..........................3 Standard accessories ................................3 About the user manuals ................................3 About the symbol mark ................................3 About HDD Unit ..................................4 Precautions for installation ................................ 4 Operations flow ........................6 Installation flow ..................................6 About the operation .................................. 6 1 Rack mounting ........................

  • Page 3: Introduction

    About the user manuals This manual describes how to install, connect, and install the HDD unit of the WJ-HXE410 Series (hereafter this product or extension unit) using an example configuration with an optional network disk recorder (WJ-NX510K Series, WJ-NX410K Series, hereinafter recorder).

  • Page 4: About Hdd Unit

    Keep this product away from water and moisture. mounted to a wall according to Installation Guide. i-PRO Co., Ltd. assumes no responsibility for injuries Place this product horizontally on a level surface. or property damage resulting from failures arising out Do not place this product in an upright position.
  • Page 5 Introduction (continued) Heat dissipation Grounding To prevent this product from overheating, heed the Confirm that the wire is connected from the SIGNAL GND following. Failure to observe this may cause fire or trouble. terminal to earth ground. • Do not block the cooling fan outlet or the ventilation holes A grounding connection must be made before connecting with a wall, rack, cloth, etc.

  • Page 6: Operations Flow

    Operations flow • Professional knowledge on and experience in network and the HDD are required for the settings and changes of the operation. • The PC is required for reading the Important Information. Installation flow The installation flow of the extension unit is as follows. Install the extension unit in the rack.

  • Page 7: Rack Mounting

    1 Rack mounting Install the recorder in an EIA standard 19-inch rack (Depth: Step 3 550 mm or more). Place the rack mounting brackets (included) on both sides of the recorder and fix them with the rack Note: mounting bracket fixing screw (included) (×6). •...

  • Page 8: Position In The Rack

    1 Rack mounting (continued) Position in the Rack This is an example where the recorder and the extension unit (max 5 units) are installed in the rack. Connect the recorder and the extension unit using the connection cable (1.5 m {4 feet 11 inches}) included in the extension unit. (☞...

  • Page 9: Connection

    2 Connection A separately sold recorder can be mounted with a maximum of 5 units. Connect the extension unit and the recorder using the included connection cable. Fix the connection cable with the included cable clamp so that it does not come off when installing the unit.
  • Page 10 2 Connection (continued) Cable clamp Step 3 Slide the cable clamp toward the connector end of the Fix the connection cable using the included cable clamp as connection cable, and then hold the connector end of follows. the connection cable. Make sure that the connection cable is connected firmly.

  • Page 11: Turn On The Devices

    3 Turn on the devices Turn on the power of the extension unit Important: • Connect the included power source cords to all the extension units and turn them on before turning on the recorder. Step 1 Connect the included power cord to the power cord inlet on the rear panel of the extension unit, and insert the power plug to an outlet whose rating is as follows.

  • Page 12: Assemble Hdd Unit

    4 Assemble HDD unit To install a hard disk drive in the recorder, it is necessary to assemble an HDD unit (encase the hard disk drive in the HDD canister). The HDD unit is designed to easily install/remove the hard disk drive in/from the recorder.

  • Page 13: Installation Of Hdd Unit

    5 Installation of HDD unit The illustration on this page is schematic. Details of the shape are omitted. It is possible to install the HDD units without stopping the operation (except when RAID1/RAID5/RAID6 mode is in operation). Do not use an electric screwdriver to avoid impact on the HDD. Step 1 Upper part of lever ➁...

  • Page 14: Troubleshooting

    Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Symptom Cause/solution Ref.
  • Page 15 Troubleshooting (continued) Inspect the power cord, power plug and connectors periodically. Symptom Cause/solution Ref. pages The power cord insulation is damaged. • The power cord, connector, or power plug is damaged. − This may result in electric shock or a fire. The power cord, plug and Unplug the power plug from the AC outlet immediately, and connectors get hot during use.
  • Page 16 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB Amsterdam, Netherlands Tokyo, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 Ls1023-1103 Printed in China...
