DIRECT SELECT CONTROL CARD
DIRECT SELECT I/O CARD
Important
1. These cards contain CMOS IC's and may be damaged by static discharge. It is advisable to
wear an earth-grounded wrist strap when handling the cards.
2. Turn off all power to the system before unplugging or plugging in connectors to the cards.
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
INSTRUCTION MANUAL
VS-900DI
VS-910DI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS-900DI and is the answer not in the manual?

Questions and answers

Related Manuals for Toa VS-900DI

Summary of Contents for Toa VS-900DI

  • Page 1 2. Turn off all power to the system before unplugging or plugging in connectors to the cards. Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference. INSTRUCTION MANUAL VS-900DI VS-910DI...

  • Page 2: Table Of Contents

    6.2. Direct Select Dial Setting ... 21 6.3. Programming PC Connection ... 22 6.4. Programming Data Entry 6.4.1. Entry when the VS-900DI alone is used ... 22 6.4.2. Entry when the VS-900DI is connected to the VS-910DI ... 22 ... 4 ... 9...
  • Page 3 8.3.1. CCTV interlock output ... 26 8.3.2. Remote door control output ... 27 8.4. Conversation Using the Master Station ... 28 8.5. Conversation Using the VS-900DI and Not Using the Master Station ... 28 9. SPECIFICATIONS Accessories ... 29 FCC REQUIREMENTS WARNING (For U.S.A.

  • Page 4: General Description

    1. GENERAL DESCRIPTION The VS-900DI Direct Select Control Card and VS-910DI Direct Select I/O Card are interface cards that connect to the VS-900 Exchange to enable calling-station indication output, direct select input, and external equipment control output functions. Because these interface cards also have a talk function, by mounting these cards in a control console in combination with a microphone or other devices, the system can be used as a substitute for the MS-900 Master Station.

  • Page 5: Basic Operation

    2.2. Basic Operation The VS-900DI Direct Select Control Card transmits, instead of the MS-900 Master Station, dial signals corresponding to key inputs. Based on information provided by the VS-900 Exchange, the VS-900DI also outputs signals for the calling station indication and external equipment control to the VS-910DI Direct Select I/O Card, which in turn controls LEDs, switches and external equipment.

  • Page 6: Nomenclature And Dimensional Diagram

    3. NOMENCLATURE AND DIMENSIONAL DIAGRAM [Direct select control card VS-900DI] 139.5 VS-900DI SJP2 SJP1 CN10 +24 V GND To MS-900 133.4 CN10 SP+ SP- ECMin GND 1. Fuse (250 V, 1 A) [F1] Protects the equipment from major electrical damage.
  • Page 7 Used to program data corresponding to each VS-900DI's terminal. 10. In-use indication output terminal [CN5] An open collector output that transmits "make" signals while the VS-900DI is in use. 11. Connector for VS-910DI card [CN1] Connects to the VS-910DI. 12. Station address setting switch [SW6] Sets the station address number depending on the line connecting the VS-900DI.

  • Page 8: Direct Select I/O Card Vs-910Di

    Input Relay Collector Output Output 6. Cable connector for VS-900DI or VS-910DI card [CN1] Connects the VS-900DI or VS-910DI, and permits connection of up to 32 VS-910DI cards. 7. Connector for VS-910DI card expansion [CN2] Connects 2 or more VS-910DI cards to the VS-900DI.

  • Page 9: System Design

    Prepare the required equipment according to the procedures below. Step 1. Determine the required number of LEDs, switches, and interlocking devices. Step 2. Determine whether or not the VS-900DI's talk function will be used. If this card function is not used, use the MS-900 Master Station for conversation.

  • Page 10: Setting The Vs-910Di Card Numbers

    When connecting 2 or more VS-910DI cards, remove the terminating resistors in CN7, CN8, and CN9, except the VS-910DI card farthest from the VS-900DI card. For the interlocking outputs to the LED, switch, or external equipment, connect them after completing all connections as shown below.

  • Page 11: Vs-900Di Connection

    5.4. VS-900DI Connection 5.4.1. Connector connection Step 1. Strip the end of the cable back approximately 5 mm. Step 2. While pressing on the upper side of the connector with a standard screwdriver as shown in the figure, insert the cable leads.

  • Page 12: Connection To The Exchange

    5.4.3. Connection to the exchange • Connect the VS-900DI to the VS-900MS using 2 twisted pair cables as shown below referring to the following procedures. 1. Fit the 4P connector (supplied with the VS-900MS) to one cable end, and a 6-position 4-contact modular jack (prepare locally) to the other cable end.

  • Page 13: Connection To The Ms-900 Master Station

    5.4.4. Connection to the MS-900 Master Station • Connect the VS-900DI to the MS-900 using 2 twisted pair cables as shown below referring to the following procedures. 1. Fit a 6-position 4-contact modular jack (prepare locally) to each cable end.

  • Page 14: Cn5 In-Use Indication Output Connection

    • Determine the appropriate resistor value depending on the amount of current (I) necessary for indication elements (LED, etc.) to be used. VS-900DI 5.4.7. CN4 Input key (C/PTT/XFER/Test key) connection Connect the input key to the switches from the CN4 connector as shown below. Each contact carries a current of 0.5 mA.

  • Page 15: Cn8 Headset Connection

    • If adding the switch, use the devices connected to CN8's Det. And G terminals as switches. • If the headset microphone is of dynamic type, cut the jumper SJP1. • Adjust the semi-fixed control VR1 for optimum microphone sensitivity. • Adjust the semi-fixed control VR3 for optimum speaker sound volume. VS-900DI Speaker Mic. R(+) R(–)

  • Page 16: Cn9 Microphone Input Connection

    Pay attention to the polarity, and be sure to connect the signal side (+) to the ECMin terminal. Note Cut the jumper SJP2 on the VS-900DI card when using a dynamic microphone or externally-powered microphone. (This work results in cutting off the phantom power supply.) Adjust the semi-fixed control VR2 for optimum microphone sensitivity.

  • Page 17: Vs-910Di Connection

    5.5. VS-910DI Connection 5.5.1. CN3 power supply terminal connection 5.5.2. Calling station indication output connection • The calling station indication output is connected to the LED from the 50-position Miniature Ribbon Plug* of CN5 according to the figure below. For the relationship between the CN5 connector pins and their corresponding outputs, refer to the table below.

  • Page 18: Direct Select Input Connection

    5.5.3. Direct select input connection Connect the direct select input from CN6's 50-position Miniature Ribbon Plug* as shown below. For the relationship between the CN6 connector pins and their corresponding inputs, refer to the table below. Each contact carries a current of 0.5 mA. * Equivalent to "CHAMP ®...

  • Page 19: External Equipment Control Output Connection

    5.5.4. External equipment control output connection Connect the external equipment control output to the equipment to be controlled from CN4's 50-position Miniature Ribbon Plug* as shown below. For the relationship between the CN4 connector pins and their corresponding inputs, refer to the following table. The contact capacity is 24 V DC/1 A.

  • Page 20: Vs-910Di's Cn4/Cn5/Cn6 Connections

    5.5.5. VS-910DI's CN4/CN5/CN6 connections Use a 50-position Miniature Ribbon Jack* the plug on the circuit board side is as illustrated below. The size of the plug on the VS-910DI card 82.8 74.9 51.816 2.159 50-position Miniature Ribbon Plug* Depending upon the type of connector to be used, the space (W* determined.

  • Page 21: Registration

    6. REGISTRATION Use the VS-900 PC interface software to register the station No. for each key input. 6.1. Direct Select Setting Connect the VS-900DI to the VS-900MF for setting. Designate the exchange number, then perform the following settings: Setting Item Control output mode Select the external equipment control output operation mode.

  • Page 22: Programming Pc Connection

    6.3. Programming PC Connection Connect the VS-900DI to the programming PC by using an RS-232C cable as shown below. VS-900DI 6.4. Programming Data Entry 6.4.1. Entry when the VS-900DI alone is used Switch on the VS-900DI's power. Enter the set data. Do not switch off the power until LEDs 1 to 8 begin to flash, which indicates data registration completion.

  • Page 23: Operation Test

    Step 3. The conversation can be terminated by means of on-hook operation or the [C] key on the master station or VS-900DI's input key or CN4's [C] key. The call transfer function can also be used by means of the VS-900DI's transfer key (CN4's [Xfer] key).

  • Page 24: Functions And Operation

    8. FUNCTIONS AND OPERATION 8.1. Calling/Called Station Indication Output Calling and called parties can be indicated on the corresponding LED indicators by making the LED indicators on the indicator panel that correspond to the stations for each master station. 1. Emergency station making a call: Quick flashes 2.

  • Page 25: Direct Select Input

    8.2. Direct Select Input If an operation panel containing switches corresponding to the stations is prepared for each master station, a desired party can be called or a calling party can be responded to by simply pressing the corresponding switch. [System pre-programming] To use the above function, both the Direct Select input switch and dial operation must be assigned and programmed by system programming.

  • Page 26: External Equipment Control Output

    8.3. External Equipment Control Output Connected external equipment can be controlled using the following 2 types of timings by making the control panel providing relay outputs that correspond to the stations for each master station. 8.3.1. CCTV interlock output Contact points corresponding to the stations open and close in synchronization with operations such as calls from other station or conversation commencement.

  • Page 27: Remote Door Control Output

    8.3.2. Remote door control output Performing the following operations during conversation with another station makes (closes) the contact point corresponding to the conversation partner's station for a specified period of time. (For example, connection to the electric lock system creates the door lock control system.) [System pre-programming] •...

  • Page 28: Conversation Using The Master Station

    (This tone will be heard from the station's internal speaker if dialed with the handset on-hook.) Step 3. Talk Step 4. Replace the handset or push the [C] key to terminate the conversation. (Either the [C] key on the master station or on the VS-900DI can be used.) Call tone Direct select key 8.5.

  • Page 29: Specifications

    [VS-900DI] Power Source 24 V DC ±10%/1 A, 2-pole screwless terminal* Maximum Cable Length 1.5 km (including the additional master station line from the VS-900DI) when to Exchange the cable guage is AWG22 Maximum Number of 4 cards per exchange, 64 cards per system (16 tie-lined exchanges)
  • Page 30 [VS-910DI] Power Source 24 V DC ±10%/1 A, 2-pole screwless terminal* Maximum Number of VS-910DIs per VS-900DIs Maximum Number of • 32 switch inputs (for calling and response switch operation) Ports per VS-910DI • 32 open collector outputs (for LED indication of incoming and outgoing calls) •...
  • Page 32 133-06-233-1A...
