- Page 1 INSTRUCTION BOOK COOKER HOOD MCH 662 cod. 4329646_06 - 040515...
- Page 2 If you require guidance in the use of the appliance or require further information on Moffat Products, please contact our Customer Care Department. For general enquiries concerning your Moffat appliance or for further information, visit our website at http:\\www.electrolux.co.uk Customer Care Department...
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department. Installation Child Safety •... - Page 4 YOUR APPLIANCE OPERATING INSTRUCTIONS This cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. To obtain the best performance it is advisable to switch on the hood a few minutes before you start cooking and leave it running for approximately 15 minutes after finishing.
- Page 5 To Operate Open the visor and select the required functions. The appliance can be installed to recirculate or extract contaminated air. The cooker hood is more effective when used in the extraction mode. Recirculation The hood is supplied specified for use in the recirculation mode with the charcoal filter/s fitted.
-
Page 6: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before carrying out any maintenance or cleaning isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fire hazard. External Cleaning Wipe the cooker hood frequently with warm soapy water using a mild detergent. -
Page 7: Changing The Lamps
Clean the metal inlet grille/s and motor support/ s before replacing the charcoal filter/s. Place the new charcoal filter/s (B) over the motor support/s (A), and while holding the filter securely insert the disk (C) and turn clockwise. This appliance can be a fire hazard if the grease and charcoal filters are not replaced as recommended. -
Page 8: Something Not Working
SOMETHING NOT WORKING If, having followed these instructions carefully, your cooker hood fails to work properly please carry out the following checks. Symptom Solution The cooker hood will not start • Check the hood is connected to the electricity supply. •... - Page 9 GUARANTEE CONDITIONS STANDARD GUARANTEE CONDITIONS We, Moffat, undertake that if within twelve months of the date of the purchase this Moffat built-in appliance or any part there of is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option repair or replace the same FREE OF ANY CHARGE for labour, materials or carriage on condition that: •...
-
Page 10: Installation Instructions
INSTALLATION INSTRUCTIONS It is dangerous to alter the specifications or attempt to modify this product in any way. Technical Information DIMENSIONS HEIGHT 350mm WIDTH: 598mm DEPTH: 270-360mm DEPTH WITH VISOR OPEN: 540-630mm WEIGHT GROSS: 12,5 kg NET: 10,9 kg ELECTRICAL SUPPLY: Voltage (~50Hz) 220-240 V POWER CONSUMPTION:... -
Page 11: Installing The Cooker Hood
INSTALLING THE COOKER HOOD Please ensure that when the appliance is installed it is easily accessible to an engineer in the event of a breakdown. All installations must comply with the local authorities requirements for the discharge of exhaust air. Incorrect installation may affect the safety of this cooker hood. - Page 12 Clearance Height A clearance height of 650mm (25 1/2 ”) is required when installed above a built-in electric hob, or 700mm (27 1/2 ”) when installed above a built-in gas hob. A clearance height of 685mm (27”) is required when installed above a slot-in electric cooker, or 787mm (30 1/2 ”) when installed above a slot-in gas cooker.
- Page 13 Venting The hood is more effective when used in the extraction setting (ducted to the outside). Venting kits may be purchased through your retailer or DIY store, and must be ducted to an outside vent of 100mm (4 ins) minimum. The ducting used must be manufactured from fire retardant material.
- Page 14 Fitting the Cooker Hood to the Wall Fit the brackets with the round ends facing downwards. Once the brackets are secured, lift the hood squarely to the wall slightly higher than the brackets and lower the cooker hood until it is located onto the two brackets.
- Page 15 To Refit the Hood with Decor Panel Attached Insert the upper visor guides into the upper track in the front of the casing. Pull down the bottom edge of the visor and insert the lower guides into the track in the bottom of the casing.
-
Page 16: Service And Spare Parts
Service and Spare Parts Before calling out an engineer, please ensure you have read the details under the heading “Something Not Working.” In the event of your appliance requiring service, or if you When you contact the Service Force Centre you will need wish to purchase spare parts, please contact your local to give the following details: Service Force Centre by telephoning:... - Page 20 55 - 77 High Street - Slough BERKSHIRE SL1 1DZ © Electrolux plc 2002...
