Installation and
Maintenance
Instructions
B-7000-SERIES
EPOXY POWDER
COATED & STAINLESS
STEEL REELS
U.S. Patent #D551,945
Español:
Instrucciones de instalación y
mantenimiento

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-7000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for T&S B-7000 Series

  • Page 1 Installation and Maintenance Instructions Limited Two Year Warranty T&S warrants to the original purchaser (other than for purposes of resale) that such product is free from defects in material and workmanship for a period of two (2) years from the date of purchase, except hose.
  • Page 2 Exploded View Enclosed Hose Reel scale 5:1 B-7102 Open Hose Reel scale 5:1...
  • Page 3: Part Number Guide

    Part Number Guide SWIVEL KITS - 1 PART NUMBER HOSE I.D. HOSE LENGTH MAX. PRESSURE 014946-45 3/8” 15’/30’/35’/50’ 300 psi 017355-45 3/8” 12’ 300 psi * 014947-45 1/2” 35’/50’ 300 psi SPRING ASSEMBLIES - 2 PART NUMBER HOSE I.D. HOSE LENGTH MAX.
  • Page 4 Part Number Guide HOSE KITS - 6 PART NUMBER HOSE I.D. HOSE LENGTH MAX. PRESSURE 017938-45 3/8” 12’ 300 psi 014944-45 3/8” 15’ 300 psi 014943-45 3/8” 30’ 300 psi 014941-45 3/8” 35’ 300 psi 014942-45 3/8” 50’ 300 psi * 015089-45 1/2”...
  • Page 5: General Instructions

    General Instructions Important Safety Instructions Important Safety Instructions DANGER: Immediate hazards which will result in severe personal injury or death. DANGER: Immediate hazards which will result in severe personal injury or death. WARNING: Hazards or unsafe practices which could result in severe personal WARNING: Hazards or unsafe practices which could result in severe personal injury or death.
  • Page 6: General Mounting Requirements

    General Instructions Installation Installation General Mounting Requirements • (Fig. 2) Main-shaft must be horizontal. • (Fig. 3a) Swivel inlet must be connected with fl exible hose. Rigid pipe may cause premature wear and affect performance. • (Fig. 3b) Centerline of spool assembly must be in-line with hose pull out. To adjust guide arm, remove screws holding it to base and rotate to desired group of mount- ing holes.
  • Page 7 General Instructions SECONDARY SUPPORT SECONDARY SUPPORT WARNING: A secondary support chain is required for all objects mounted over WARNING: A secondary support chain is required for all objects mounted over head to head to protect personnel in case of failure in mounting hardware or structure. protect personnel in case of failure in mounting hardware or structure.
  • Page 8: Tension Adjustment

    General Instructions TENSION ADJUSTMENT TENSION ADJUSTMENT CAUTION: Always leave at least 1-2 turns between full extension and when the CAUTION: Always leave at least 1-2 turns between full extension and when the spring spring is wound tight. If entire hose cannot be pulled out, decrease tension is wound tight.
  • Page 9 General Instructions RATCHET LOCK REPLACEMENT/REMOVAL RATCHET LOCK REPLACEMENT/REMOVAL Fig. 10.1 To replace or remove ratchet: • Turn off or lockout air/fl uid supply to reel • Remove all tension, see “Tension Adjustment” • (Fig. 10.1) Remove spool from stand (24mm or 22mm nut) •...
  • Page 10: O-Ring Replacement

    General Instructions B-7102 MAIN-SPRING ASSEMBLY REPLACEMENT B-7102 MAIN-SPRING ASSEMBLY REPLACEMENT To replace model B-7102 main spring: • Turn off or lockout air/fl uid supply to reel and bleed off remaining pressure. Re- move supply hose to inlet swivel. • Remove all tension; see “Tension Adjustment.” Unwind hose from reel and remove hose clamp (8mm nut).
  • Page 11 General Instructions Preventative Maintenance Preventative Maintenance HOSE • Check wear near hose-stop and end fi tting. If barb fi tting or hose is damaged cut off hose end and reattach new barb fi tting and clamp. • Check wear along entire hose length. Replace if needed. SWIVEL •...
  • Page 12: Instrucciones Generales

    Instrucciones generales Instrucciones adicionales de seguridad Instrucciones adicionales de seguridad PELIGRO: Peligros inmediatos que pueden provocar graves lesiones o la muerte. PELIGRO: Peligros inmediatos que pueden provocar graves lesiones o la muerte. ADVERTENCIA: Prácticas peligrosas o inseguras que pueden provocar graves ADVERTENCIA: Prácticas peligrosas o inseguras que pueden provocar graves lesiones o la muerte.
  • Page 13 Instrucciones generales Instalación Instalación Requisitos generales de montaje • (Fig 2) El eje principal debe de estar horizontal. • (Fig 3a) La entrada de la rótula debe estar conectada con la manguera fl exible. Un tubo rígido puede provocar desgaste prematuro y afectar el desempeño. •...
  • Page 14 Instrucciones generales SOPORTE SECUNDARIO SOPORTE SECUNDARIO ADVERTENCIA: Se requiere una cadena de soporte secundario para todos los ADVERTENCIA: Se requiere una cadena de soporte secundario para todos los objetos montados en altura para proteger al personal en caso de falla en la objetos montados en altura para proteger al personal en caso de falla en la montura o la estructura.
  • Page 15: Ajuste De La Tensión

    Instrucciones generales AJUSTE DE LA TENSIÓN AJUSTE DE LA TENSIÓN PRECAUCIÓN: Siempre deje por lo menos 1-2 vueltas entre la extensión completa PRECAUCIÓN: Siempre deje por lo menos 1-2 vueltas entre la extensión completa y cuando el resorte está bien enrollado. Si no se puede sacar la manguera y cuando el resorte está...
  • Page 16 Instrucciones generales REEMPLAZO Y RETIRO DEL BLOQUEO DEL TRINQUETE REEMPLAZO Y RETIRO DEL BLOQUEO DEL TRINQUETE Para reemplazar o quitar el trinquete: Fig. 10.1 • Apague o bloquee el abasto de aire o líquido al carrete. • Quite todas las tensiones; vea "Ajuste de tensión". •...
  • Page 17 Instrucciones generales REEMPLAZO DEL CONJUNTO DEL RESORTE PRINCIPAL EN B-7102 REEMPLAZO DEL CONJUNTO DEL RESORTE PRINCIPAL EN B-7102 Para reemplazar al resorte principal en el modelo B-7102: • Apague o bloquee el abasto de aire o líquido al carrete y elimine la presión restante.
  • Page 18 Instrucciones generales Mantenimiento preventivo Mantenimiento preventivo MANGUERA • Revise si hay desgaste cerca del paro de la manguera y del conector del extremo. Si el conector estriado o la manguera están dañados, corte el extremo de la manguera y fi je un nuevo conector estriado y abrazadera. •...
  • Page 19 ACCESSORIES ACCESSORIES PART NUMBER PART DESCRIPTION HOSE LENGTH MAX. PRESSURE G016636-45 Swing Bracket 3/8” x 12’ , 15’ , 30’ , 35’ G016637-45 Swing Bracket 3/8” x 50’; ALL 1/2” G016737-45 S/S Swing Bracket G016652-45 Pivot Bracket Stainless Steel Swing Bracket Swing Bracket B-0963 Pivot Bracket...
  • Page 20: Maintenance Instructions

    Installation and Maintenance Instructions Limited One Year Warranty T&S warrants to the original purchaser (other than for purposes of resale) that such product is free from defects in material and workman- ship for a period of one (1) year from the date of purchase.
  • Page 21 Exploded View...
  • Page 22 Grey Grey Part Number Guide PARTS PARTS FOR ANY GREY T&S SPRAY VALVE Ring, Hold Down 000907-45 1,2,3 #27 Washer 010476-45 Body, Spray Valve 000065-40 Grey Handle 001120-45 Nut, Handle 003198-45 Screw, Handle 003199-45 PARTS FOR ANY GREY BONNET ASSEMBLY Bonnet Assembly 002856-40 1,2,3...
  • Page 23 Blue Blue Part Number Guide PARTS PARTS FOR ANY BLUE T&S SPRAY VALVE Ring, Hold Down 000907-45 4,5,6,7 #27 Washer 010476-45 Body, Spray Valve 000065-40 Blue Handle 011454-45 Nut, Handle 003198-45 Screw, Handle 003199-45 PARTS FOR ANY BLUE BONNET ASSEMBLY Bonnet Assembly 010594-40 4,5,6,7...
  • Page 24 General Instructions 8. For EB-0107/UK-0107 & B-0107 To replace worn parts: ONLY: To replace no.9, unscrew 1. Shut off water supply and drain no.11 and disassemble. Make sure lines. For ease of disassembly and the groove side of no.9 fi ts over reassembly, the handle grip can be no.8, and no.10 rest on ridge side.
  • Page 25 RELATED T&S BRASS PRODUCT LINE B-0108 JeTSpray Spray Valve B-0108-C JeTSpray Low Flow Spray Valve T&S BRASS AND BRONZE WORKS, INC. A fi rm commitment to application-engineered plumbing products 2 Saddleback Cove, P.O. Box 1088, T & S Brass-Europe Travelers Rest, SC 29690 ‘De Veenhoeve’...
  • Page 26 Installation and Maintenance Instructions Limited One Year Warranty T&S warrants to the original purchaser (other than for purposes of resale) that such product is free from defects in material and workmanship for a period of one (1) year from the date of purchase.
  • Page 27: Exploded View

    Exploded View * Some items are listed for instructional purposes and may not be sold as separate parts.
  • Page 28 Part Number Guide B-0108 Spray Valve Grip, Spray Valve Bugle, Spray Valve Washer Check Valve Spray Face, Spray Valve Body, Spray Valve Liner, Spray Valve Face Seal, Spray Valve Stem Asm, Spray Valve Spring, Compression Plug, Spray Valve Screen, Spray Valve Close Nipple Screws Pivot Pin, Spray Valve...
  • Page 29 General Instructions Installation: 1. Shut off water supply and drain lines. 2. Remove old spray valve from hose, including handle if applicable. (See images 1 & 2) Note: Make sure that the hose washer is still in place inside the hose barrel before install- ing your new Jet Spray valve.
  • Page 30 General Instructions DC-111 Silicone Grease (1) 1/4” Spanner Bit (1) End Plug Assembly (1) Valve Repair Compression Assembly (1) Spring (1) B-0108 Valve Repair Kit -- 108V-RK 1. Shut off water supply to spray valve. 2. Using the 1/4” spanner bit, unscrew the end plug. Note: Be careful in removing end plug;...
  • Page 31 General Instructions Contractor_______________________________________ SS TRIGGER(1) Architect/Engineer_________________________________ SPRING/TRIGGER CATCH/SCREW SUBASSEMBLY(1) DC-111 SILICONE GREASE(1) LOCTITE 222 TRIGGER SCREW(1) 6-32 X 3/8" PIVOT PIN SCREW(2) ASSEMBLY(1) B-0108 Trigger Repair Kit -- 108T-RK 1. Shut off water supply to spray valve. 2. Using two phillips head screwdrivers, remove the two screws retaining the trigger handle.
  • Page 32 General Instructions Inlet Filter (1) Loctite 222 (1) B-0108 Inlet Screen/Washer Repair Kit -- 108S-RK To replace the inlet screen/washer between the top of the valve body and the 7/8”-20 adapter. 1. Shut off water supply to spray valve. 2. By inserting a 3/8” L-wrench into the 7/8”-20 adapter, unscrew and remove the adapter as well as the screen and washer.
  • Page 33 General Instructions Washer (1) B-0108 Low Flow Spray Face (1) B-0108 Low Flow Spray Face Repair Kit -- 108CSF-RK EPAct 2005 Compliant 0.65 GPM Fan Spray Repair Kit 1. Shut off water supply to spray valve. 2. With hand or pliers, use center ribs to turn the spray face counter-clockwise and re- move spray face and washer.
  • Page 34 General Instructions Washer (1) B-0108 High Flow Washer (1) B-0108 1.48 GPM Spray Face (1) Spray Face (1) HIGH FLOW REGULAR FLOW B-0108 Spray Face Repair Kits 108HSF-RK -- High Flow Spray Face 108SF-RK -- EPAct 2005 Compliant 1.48 GPM Spray Face 1.
  • Page 35 RELATED T&S BRASS PRODUCT LINE B-0107 Pre-Rinse Spray Valve 1.42 GPM - EPAct 2005 Compliant B-0107-C Low Flow Pre-Rinse Spray Valve 0.65 GPM - EPAct 2005 Compliant T&S BRASS AND BRONZE WORKS, INC. A fi rm commitment to application-engineered plumbing products 2 Saddleback Cove, P.O.
