DIVERTER TRIM
INSTALLATION
Model #:
AG231-1
BEFORE YOU BEGIN YOUR INSTALLATION:
1
Turn o water supply.
REQUIRED TOOLS AND MATERIALS:
Flat Screwdriver
WARNING: Cancer and reproductive harm - see www.P65Warnings.ca.gov
IMPORTANT!
• Read these instructions and plan the installation before beginning.
• Risk of product damage. Do not apply direct heat to the valve. Excessive heat will damage the plastic components and plaster guard.
• Do not remove the plaster guard until instructed to do so.
• A water supply is required for this valve.
• Component location, spacing, and situational requirements can vary.
2
Observe all local
plumbing codes.
Adjustable Wrench
3
Inspect plumbing for signs of
damage. Replace as necessary.
Channel Locks
4
DO NOT use petroleum based
products on this faucet.
Coping Saw
Advertisement
Table of Contents
Related Manuals for Waterstone AG231-1
Summary of Contents for Waterstone AG231-1
- Page 1 DIVERTER TRIM INSTALLATION Model #: AG231-1 BEFORE YOU BEGIN YOUR INSTALLATION: DO NOT use petroleum based Turn o water supply. Observe all local Inspect plumbing for signs of plumbing codes. damage. Replace as necessary. products on this faucet. REQUIRED TOOLS AND MATERIALS:...
- Page 2 Remove and discard mud cover (A) from 3/4” MIN rough-in valve (B), 10121. Remove all thread (C) from valve. Remove stem extension (D) from Measure and trim to the needed length valve. Trim the stem extension at the of thread to engage plate collar (F). second notch.
