Page 1: Installation Instructions
CONTEMPORARY PLP PULLDOWN FAUCET INSTALLATION INSTRUCTIONS Model #s: 5300, 5400, 5410, 5700, 5800, 5810, 5900, 5910, 5930, 5940 5300 5400 5900 5410 5940 5700 5800 5930 5810 5940... -
Page 2: Before You Begin Your Installation
Channel Locks HANDLE POSITION Waterstone faucets are designed to be installed in 3 different faucet positions. Choose to have the handle on left, front or right. Your faucet is factory configured for the most common positions - a front and right side installation. - Page 3 On some kitchen countertops, the handle may hit the backsplash when the faucet handle is positioned to the left or right (Fig. 1). Waterstone gives you the option of adjusting the handle 22.5 degrees to avoid hitting backsplash. CONNECTING SUPPLY HOSES...
- Page 4 CLEANING DEBRIS SCREEN CLEANING AERATOR - TOGGLE SPRAYER 1. Turn off water supplies underneath sink and remove any water pressure by opening the faucet handle. 2. Unscrew sprayer (A) from spray hose by holding knurled swivel (B). 3. Inspect, remove and clean debris screen (C) in sprayer.
- Page 5 INSTALL SOAP/LOTION DISPENSER (OPTIONAL) 1-3/8” HOLE Pull and remove spout (A) from dispenser body (B). Remove clamp nut COUNTER (C) and brass spacer (D) OR SINK from threaded shroud. Fit dispenser body through 1-3/8” hole on counter or sink. (No plumbers putty is required).
- Page 6 CONTINUED FROM PREVIOUS PAGE GARBAGE DISPOSAL Slide other end of tubing (F) into tube Plug control box into undersink fitting at bottom of Tighten clamp screws (E) Hand tighten switch base back electrical outlet. Plug garbage securely with screwdriver. down to cover threads. control box (G).
- Page 7 INSTALL DUAL PORT AIR GAP (OPTIONAL) 1-1/2” HOLE Slide gasket down and screw Pull air gap (A) off of upper cap Unscrew and remove top clamp From underneath counter top clamp nut back onto piping. Adjust the two clamp nuts to nut (B).
