Waterstone HUNLEY Series Manual

Kitchen faucets
Hide thumbs
1
2
3

Advertisement

Table of Contents

HUNLEY SERIES KITCHEN FAUCETS

Before you begin your installation:

1.
Make sure your water supply is turned off
2.
Observe all local plumbing codes
3.
Inspect waste and water supplies for any signs of
damage and replace as necessary
4.
Do not use petroleum based products on this faucet.

Recommended Tools and Materials

1.
Phillips Screwdriver
2.
Adjustable Wrench
FAUCET INSTALLATION (see diagram)
1.
Remove the clamp nut (A) and washer (B) from the threaded
shroud (C) under the faucet and fit the faucet flexible
hoses and rigid sidespray tube through the hole on the
counter or sink. (No plumbers putty is required in that the
faucet has an O-ring seal built into its base).
2.
Slide the washer and thread the clamp nut onto the threaded
shroud. Make sure clamp screws are screwed back and
thread the nut snug to the underside of the sink or counter.
3.
Make sure the faucet is in the correct position you want it for
your sink and securely tighten the clamp screws.

CONNECT SUPPLY HOSES

1.
Carefully position the hot and cold supplies so they will not
interfere with other hoses
2.
Connect the supply hoses to the supply stops

INSTALLATION INSTRUCTIONS

3600-XX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HUNLEY Series and is the answer not in the manual?

Questions and answers

Related Manuals for Waterstone HUNLEY Series

Summary of Contents for Waterstone HUNLEY Series

  • Page 1: Installation Instructions

    INSTALLATION INSTRUCTIONS HUNLEY SERIES KITCHEN FAUCETS 3600-XX Before you begin your installation: Make sure your water supply is turned off Observe all local plumbing codes Inspect waste and water supplies for any signs of damage and replace as necessary Do not use petroleum based products on this faucet.
  • Page 2 Note the most common faucet installation is with the handle positioned to the right. Pull the handle for hot water or push the handle for cold water. If the handle is centered, press it to the right for cold and to the left for hot water If the handle is installed to the left, reverse the supply hoses (connect the hose for cold water to the hot supply and the hose for hot water to the cold supply).
  • Page 3 2- Using a needle nose pliers or small hook, remove old diverter (b) by pulling it straight up. 3- Insert the new diverter (c) by pushing straight down. (Use a little liquid soap to lubricate the o-rings before installation). WATERSTONE 4- Re-install riser base, check for leaks.
