TIS 850 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VOLTAGE TESTER
DIGITAL VOLTAGE & CONTINUITY TESTER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 850 and is the answer not in the manual?

Questions and answers

Related Manuals for TIS 850

Summary of Contents for TIS 850

  • Page 1 VOLTAGE TESTER DIGITAL VOLTAGE & CONTINUITY TESTER...
  • Page 2 1. FEATURES • Self diagnostic test • AC and DC voltage tests up to 690V for Europe with LED and LCD • Polarity indication • Phase rotation test • Continuity test...

  • Page 3: Safety Warning

    • Auto power ON/OFF • Pen light for illuminating measurement points • Probe clip for adjustable spacing between probes • Probe cover protects user and probe tips • IP 64 • Compact design, light weight and portable • H07RNF compliant cable in accordance with European standards 2.

  • Page 4: Preparation For Measurement

    12/24/50/1 20/230/400/690V LEDs.for European voltage indication ○1 ○2 L/R LEDs for phase rotation test ○3 Power LED ○4 Polarity indication LEDs for voltage ○5 LCD ○6 Continuity test /Live circuit LED ○7 Hight voltage indication > 50V, LED will light up (1).
  • Page 5 • Auto Power-on • Short-circuiting the probes as follows powers on the instrument automatically and goes into a self- diagnostic test. Instrument may power on due to the influence of static charge. ALWAYS PROVE THIS TESTER ON A KNOWN LIVE SOURCE BEFORE AND AFTER TEST. ■...

  • Page 6: Phase Rotation Test

    WARNING Carefully check Clause 2 also. • Self-diagnostic test should be done prior to measurements to confirm that LEDs and buzzer work properly. • Before using a voltage tester with audible indication, please make sure that the background noise level is not •...

  • Page 7: Continuity Test

    ► L LED indicates that the field is rotating towards the left direction of the “probe -”. With this connection, the motor will go negative rotation. The principle of measurement The instrument detects the phase rising order in relation to the user to EARTH. NOTE Function of this test may not be fully achieved if the insulation condition of the user or of the equipment under test is not good enough.

  • Page 8: Specifications

    ►Pull out the Battery case and replace the batteries. Insert new batteries according to the symbols on the Battery case. ►Insert the Battery case into the instrument and firmly lock the case again. WARNING Confirm that the Battery case is properly locked prior to measurements. 8.

  • Page 9: Measurement Category

    Reference condition Battery 3V (AAA 1.5V x 2pcs) -10 ~ 55ºC Operation Temperature -20 ~ 60ºC Storage No condensation Humidity Max. 85% RH Operating altitude Altitude up to 2000m Safety Standard category EN 61243-3/ IEC 61243-3 EN 61010-1/ IEC 61010-1 CATIII 690V /CAT IV 600V Pollution degree IP code...
  • Page 10 Ingress protection numbers are used to specify the environmental protection – electrical enclosure – of electrical equipment. The IP rating normally has two numbers: The first number – protection against solid objects. The second number – protection against liquids. IP64: The instrument is totally protected against dust and against water sprayed from all directions.
