VOLTAGE TESTER
VOLTAGE TESTER
INSTRUCTION MANUAL
TIS 851

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 851 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TIS 851

Summary of Contents for TIS 851

  • Page 1 VOLTAGE TESTER VOLTAGE TESTER INSTRUCTION MANUAL TIS 851...

  • Page 2: Safety Warning

    1. FEATURES • Self diagnostic test • AC and DC voltage tests up to 690V for Europe with LED and LCD(TIS 851) • Polarity indication • High voltage indication • Phase rotation test • Continuity test • Auto power ON/OFF •...

  • Page 3: Instrument Layout

    ○1 ○3 L/R LEDs for phase rotation test ○4 Power LED ○5 Polarity indication LEDs for voltage ○6 LCD (only TIS 851) ○7 Continuity test /Live circuit LED ○8 Hight voltage indication > 50V, LED will light up (1). L1 probe - (2).

  • Page 4: Preparation For Measurement

    4. Preparation for Measurement 4.1 Self-Proving Test Please touch the two probes together and press the torch button (5); all LEDs shall light up, except the • “POWER” LED. Please do the “Self-Proving Test” before and after the measurements, which proves the instrument’s •...

  • Page 5: Phase Rotation Test

    Voltage test (Double-pole test) ► Connect both probes to the object under test. ► The voltage is indicated by LEDs and LCD(only TIS 851 ). Live circuit LED lights up: ≥ 7V ► Voltage polarity is indicated in following manner.

  • Page 6: Continuity Test

    ► L LED indicates that the field is rotating towards the left direction of the “probe -”. With this connection, the motor will go negative rotation. The principle of measurement The instrument detects the phase rising order in relation to the user to EARTH. NOTE Function of this test may not be fully achieved if the insulation condition of the user or of the equipment under test is not good enough.

  • Page 7: Specification

    ►Insert the Battery case into the instrument and firmly lock the case again. WARNING Confirm that the Battery case is properly locked prior to measurements. 8. Specification Voltage test Voltage range 12 ~ 690V AC/DC LED (TIS 851) Nominal voltage Europe: 12/24/50/120/230/400/690V Tolerance Light on at more than (Threshold voltage) 7±5V (12V LED)
  • Page 8 Internal battery consumption Approx. 30mA (battery 3V, 0Ω) Reference condition Battery 3V (AAA 1.5V x 2pcs) -10 ~ 55ºC Operation Temperature -20 ~ 60ºC Storage No condensation Humidity Max. 85% RH Operating altitude Altitude up to 2000m Safety Standard category EN 61243-3/ IEC 61243-3 EN 61010-1/ IEC 61010-1 CATIII 690V /CAT IV 600V...
  • Page 9 13. Ingress protection (IP) ratings Ingress protection numbers are used to specify the environmental protection – electrical enclosure – of electrical equipment. The IP rating normally has two numbers: The first number – protection against solid objects. The second number – protection against liquids. IP64: The instrument is totally protected against dust and against water sprayed from all directions.
