- Page 1 Installation Instructions Ecostat 1001 SL Bath/Shower 13241000 Ecostat 1001 SL Ecostat 1001 SL Shower Shower 13261000 13278000...
-
Page 2: Table Of Contents
Contents Safety and Important Information Pack Contents Diniensions Technical Data Supply Conditions TMV2 Supply Conditions TMV3 The Ecostat 1001 SL Bath/Shower 1341000 Installation Requirements meets the requirements of the TMV Scheme. Installation Thermostat Commissioning and in-service tests Commissioning In-service tests Frequency of in-service tests Thermostatic Adjustement Temperature Limitation... -
Page 3: Safety And Important Information
Safety and Important Information Hansgrohe products are safe provided they are installed, used and maintained in accordance with these instructions and recornrnendations. Please read these instructions thoroughly and retain for future use. The plumbing installation of this shower must comply with the requirements of UK Water Regulations/Bylaws (Scotland), Building Regulations or any other regulations specified by the local Water Authority and supplier. -
Page 4: Pack Contents
Dimensions Pack Contents Please check that you have been supplied with the following: Ecostat 1001 SL Bath/Shower Ecostat 1001 SL Bath/Shower 1 Ecostat 1001 SL 3 Escutcheons 2 Mesh washers 4 S-unions Ecostat 1001 SL Shower Ecostat 1001 SL Shower 1 Ecostat 1001 SL Escutcheons Ecostat 1001 SL Shower... -
Page 5: Supply Conditions Tmv2
Ecostat 1001 SL This thermostatic valve will suit supplies of: HIGH PRESSURE (HP-S) Bidet 38°C max. Shower 41°C max. Operating pressure: max. 10 bar Washbasin 41°C max. Recommended operating pressure: 1 - 5 bar Bath (44°C fill) 44°C max. Test pressure: 16 bar Bath (46°C fill) 46°C max. - Page 6 compliance with current Water Regulations. If you have any doubts about the Water Regulation require- ments contact your local water services provider or use the services of a professional plumber. This mixer valve is suitable for use with the following water supply systems: Gas Combination Boiler (multi-point) 1.0 - 10 bar* Unvented System (pressure balanced) 1.0 - 10 bar...
- Page 7 Unvented System (pressure balanced) Pumped System...
-
Page 8: Installation
Installation Shower Thermostat PTFE tape 150 mm COLD 32 - 41 Seal Shower Thermostat Bath/Shower Thermostat 1. The hot and cold water outlets should be 150mm As the shower thermostat above (positioned over apart (plus or minus 12mm). Hot on the left and a bath). -
Page 9: Thermostat
Shower Thermostat 180 mm COLD Shower Thermostat 1. The hot and cold water outlets must be exactly 180mm apart. Hot on the left and cold on the right (fig. 1). 2. Flush through the hot and cold water supplies. 3. Fasten the thermostatic mixer onto the unions using the union nuts. -
Page 10: Commissioning And In-Service Tests Commissioning
Commissioning and in-service tests Commissioning record the equipment, thermometer etc. used for the measurements Purpose Table A: Guide to maximum stabilised Since the installed supply conditions are likely to temperatures recorded during site be different from those applied in the laboratory tests tests it is appropriate, at commissioning, to carry Application... -
Page 11: In-Service Tests
In-service tests Frequency of in-service tests TMV3* Purpose General The purpose of in-service tests is to regularly monitor In the absence of any other instruction or guidance and record the performance of the thermostatic on the means of determining the appropriate fre- mixing valve. -
Page 12: Thermostatic Adjustement
Thermostatic Adjustment Temperature Limitation The temperature is limited by the safety stop to 40°C. If a higher temperature is required, it is possible to over ride the safety stop by depressing the safety button. NB. It is recommended that for private domestic use the maximum mixed water temperature be set 40°... -
Page 13: Setting Thermostat Max. Temp
Setting thermostat to a maximum tempe- rature (Optional) The desired maximum temperature (43°C) can be pre-set using the safety function. Proceed as follows: 1. Remove the handle end cap, undo the screw and pull off the handle and safety set disk. Remove the circlip from the spindle and slide off the locking ring (fig.1). -
Page 14: Operating Your Shower
Operating your Shower Ecostat 1001 SL Shower Flow ON/OFF Control Turn the flow control handle (fig.1a) anti-clockwise to turn the water on and to increase the flow. Turn it clockwise to decrease the flow and turn off. Temperature Control Turn the temperature control handle (fig. 1b) anti- clockwise to increase the water temperature and clockwise to decrease the water temperature. -
Page 15: Cleaning
Cleaning Cleaning materials for Mixers and Sho- wers Acids are necessary ingredients of cleaning materi- als for removing lime. However please pay particu- lar attention to the following points when cleaning mixers and showers: Only use cleaning material specifically intended for this type of cleaning - such as Hansgrohe’s Decalcifying Agent, available through the spe- cialist sanitary trade. -
Page 16: Spare Parts
Spare Parts Bath/Shower Thermostat NV15/ DN15 Thermostatic element 94282000 Shut off and diverter unit 96509000 Handle for shut off and diverter unit 96619000 Check valve NV15/ DN15 96737000 S-unions 94140000 Escutcheon 96467XXX Safety set for temperature control 95041000 Handle for temperature control 96618000 Filter packing 96922000... - Page 17 Spare Parts Shower Thermostat NV15/ DN15 Thermostatic element 94282000 Shut off unit 94149000 Handle 96618000 Check valve NV15/ DN15 96737000 S-unions 94140000 Escutcheon 96467XXX Safety set for temperature control 95041000 Safety set for flow control 95042000 Filter packing 96922000 10 Noise reduction 96429000...
-
