www.insigniarange.com
Last Modified: 07/10/2015
www.insigniarange.co.uk
INSTALLATION MANUAL
30 Day Technical Support:
01908 226545
GT8727
(NOTE: This service is only available to customers from the day of delivery,
please have your supplier's details and your postcode to hand before calling)
Replacements Parts:
inside of your warranty contact:
www.insigniarange.co.uk/customerService.aspx
Spares/Replacements Parts:
outside of your warranty
contact 0844 800 3069
ATTENTION INSTALLERS:
These instructions must be
left with the customer
WARRANTY REG NO: __________________________
to claim your full 5 year warranty, register your shower within 90 days at: www.insigniarange.co.uk/warrantyreg.aspx
Advertisement
Related Manuals for Insignia GT8727
Summary of Contents for Insignia GT8727
- Page 1 INSTALLATION MANUAL 30 Day Technical Support: 01908 226545 GT8727 (NOTE: This service is only available to customers from the day of delivery, please have your supplier’s details and your postcode to hand before calling) Replacements Parts: inside of your warranty contact: www.insigniarange.co.uk/customerService.aspx...
-
Page 2: Table Of Contents
www.insigniarange.com Last Modified: 07/10/2015 Contents Introduction Electrical Requirements What’s In The Boxes? Screw Pack Contents Plumbing Requirements Starting The Installation Electric Box Connections Steam Generator Connections Sealing and Water Testing MK117 Control Panel Instructions Help Book Information Parts list... - Page 3 Last Modified: 07/10/2015 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
- Page 4 www.insigniarange.com Last Modified: 07/10/2015 ASSEMBLY AND SIMPLE PLUMBING THIS PRODUCT BUILD IS RATED SUITABLE FOR DIY PURPOSES PROVIDING THE CUSTOMER IS OF ABOVE AVERAGE SKILLS AND FEELS CONFIDENT IN THEIR ABILITY. ONLY YOU THE CUSTOMER WILL KNOW THIS SO BEFORE ANY ATTEMPT IS MADE TO ASSEMBLY READ THROUGH THE FOLLOWING PAGES IN DETAIL THEN DECIDE.
- Page 5 www.insigniarange.com Last Modified: 07/10/2015 YOU WILL NEED TOTAL ELECTRICAL REQUIREMENTS Voltage Rating 220 -240AC Frequency Rating 50HZ Power Rating 3.0KW Other than steam generator Internal Circuit Voltage is Internal Current Rating 0.17A Your electrical contractor should understand ALL legal requirements of connection before undertaking any work or installation. UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF!!! Note for electrician.
-
Page 6: What's In The Boxes
www.insigniarange.com Last Modified: 07/10/2015 Whilst the next steps show you how to assemble your shower we want to make sure you have a correct build to ensure you get a trouble free shower. Therefore our advice is to follow the instructions and perform a dry run to ensure you are confident with the build and you understand fully how the unit is assembled. When we use the word “DRY RUN”... - Page 7 Note: In some cases you may have more screws than needed, this is done so you have spares! VERY IMPORTANT Have you got everything? If not please contact the Insignia Support Line on 01908 226545. Remember NEVER book your tradesman until everything has arrived, been checked and is present.
- Page 8 www.insigniarange.com Last Modified: 07/10/2015 Pressure Requirements from your house supply We recommend a bar pressure between 2 and 3.4 BAR. If you have a combi boiler system no problem should be experienced. If you have a gravity feed older type installation (hot water tank type usually less than 1 bar) you will almost certainly need a pump.
- Page 9 www.insigniarange.com Last Modified: 07/10/2015 TO START Make sure you have a clear space, remember when finished and in place you need access to check your build and able to pull the shower out for servicing or should you have the need to replace anything! Take the shower tray and remove all the protective wrapping and fit the waste.
- Page 10 Please note the ‘U’ shaped channel is meant to face inwards to allow the glass to fit correctly. (wider rail with Insignia logo at the top) PLEASE NOTE The screw head needs to bypass the OUTER hole.
- Page 11 www.insigniarange.com Last Modified: 07/10/2015 Step 4 Now attach your inner uprights to your front fixed glass panels by inserting these over the thin rubber seals as shown by the arrows in the image. Next screw the inner uprights to your curved rails using the ST20 screws. (please note that the front uprights will need a pilot hole drilled before screwing) Step 5 Now meet the front of the shower with the back panels.
- Page 12 www.insigniarange.com Last Modified: 07/10/2015 Step 6 Align the roof with your shower walls and using the ST25 screws and SW9 washers fix the back walls to the roof by screwing upwards from the rear of the shower and repeat this process to fix to the tray as indicated in the images Using ST20 Screws please fix the panels to the tray Step 7 Fit the adjustable wheels to the top and bottom of the glass doors and ensure the wheels...
- Page 13 www.insigniarange.com Last Modified: 07/10/2015 Accessory Installation Please Note Ensure all grey backing film on the rear of the glass panels are pierced through the existing glass holes with a knife to provide an efficient smooth fitting and location of the accessories. We recommend using a screwdriver on the smaller holes.
- Page 14 www.insigniarange.com Last Modified: 07/10/2015 Hand Shower Attach the chrome riser bar to the glass wall ensuring the water inlet is inserted through the lower large hole and hand tightened from the rear side. Now tighten the chrome shower holder ensuring that this will take the hand shower itself without falling (please note over tightening will prevent the holder from sliding up and down) Thermostatic Probe...
- Page 15 Shower Valve Device output may differ from the image. Please refer to your outer chrome faceplate in- side your Insignia shower as a reference point. IF YOUR DIAL DOES NOT CORROSPOND TO THE APPROPRIATE DEVICE: Turn on your water to the shower and note which output the water exits from then turn off the water and swap over the relevant hose.
-
Page 16: Electric Box Connections
www.insigniarange.com Last Modified: 07/10/2015 Electric Box Connections Connect the cables below to the corresponding devices on the shower Light 2 Ozone (o3) Light Speaker Earth Radio Aerial Phono (AUX, CD/MP3) RJ11 Phone Connection Thermostatic Probe... - Page 17 www.insigniarange.com Last Modified: 07/10/2015 Connection For Tray & Column Lights Using the supplied extension lead, please connect the end with the single connection to your tray lights. Next bring the extension lead up the back of the shower and connect one of the plugs to the column lights (essentially bridging the two sets of lights together) Now with the remaining connection, connect this into the wire coming from the electric box with the column light sticker on (as shown in the image)
-
Page 18: Steam Generator Connections
www.insigniarange.com Last Modified: 07/10/2015 Steam Generator Connections The steam generator has 3 connections. Steam Outlet: Connect the white insulated hose to the white steam pod within your shower. Make sure these are fitted in the correct position as they are only attached for transportation reasons only. - Page 19 www.insigniarange.com Last Modified: 07/10/2015 Silicone Seal where shown in red on the inside of the shower TESTING FOR WATER LEAKS LEAVING SHOWER 24 HOURS AFTER BUILD ALLOWING SEALENT TO CURE With all connections tight, the waste and hoses checked, jets fully sealed, your shower still around 18 inches from its designated final resting point and the silicone fully cured (hence leaving for 24 hours minimum) Switch on the overhead shower NOT the massage jets, remember these will fire water out at you and are not suitable for checking leaks as they would normally only operate when a person is in front of them.
-
Page 20: Mk117 Control Panel Instructions
www.insigniarange.com Last Modified: 07/10/2015 MK117 Control Panel Instructions Button 1 (Light Bulb) Button 7 (Down Arrow) Press 1x For Top Light Channel select down/manual search Press 2x For Column Light Press 3x For All Lights Button 8 (TUN) Press 4x To Switch Off Lights Switch Between manual &... - Page 21 Last Modified: 07/10/2015 Need Help? If so then simply download Insignia’s free comprehensive help and troubleshooting brochure now! Simply visit: www.insigniarange.co.uk/help.aspx...
-
Page 22: Parts List
Parts List Internal Items Framework SP038 Speaker Part Code Part Description Part Code Part Description SP063 Monsoon Shower head SP007 GT8727-9 Bottom Rail SP056 Ozone Module (for Steam SP037 Fan & speaker cover GT8727-7 Top rail Showers) GT8727-8 Left upright SP164... - Page 23 All images are registered with ImageTraker Insignia™ is a registered trademark of Maclean International Ltd All images are subject to copyright. Images may not be used in any way shape or form with out written permission from Maclean International Ltd. Images are NOT permitted...
