YOUR INDUCTION HOB

Description

2
1
1. Cooking zone 'Flex Induction": 180x220 mm / 2.1 kW (3.0 kW in Boost)
2. Cooking zone 'Flex Induction": 180x220 mm / 1.6 kW (1.85 kW in Boost)
Bridge zone Left (zone 1+2): 400x220 mm / 3,0 kW
▷
3. Cooking zone 'Flex Induction": 180x220 mm / 1.6 kW (1.85 kW in Boost)
4. Cooking zone 'Flex Induction": 180x220 mm / 2.1 kW (3.0 kW in Boost)
Bridge zone Right (zone 3+4): 400x220 mm / 3.0 kW
▷
5. Cooking zone ø 200 mm / 2.3 kW (3.0 kW Boost)
6. Cooking zone ø 160 mm / 1.4 kW
7. Cooking zone ø 200 mm / 2.3 kW (3.0 kW Boost)
8. Cooking zone ø 160 mm / 1.4 kW
9. Control panel
4
9 3
7
6
9
5 8
EN 5
