Appendix

If you need detailed information about the controls, please use the advanced menu.
<How to use the advanced menu>
• Turn off your monitor.
• Turn on your monitor by pushing the "POWER" and "INPUT/SELECT" button at the same time for at least one second
simultaneously. Then press the control buttons (EXIT, LEFT, RIGHT, UP, DOWN).
• You will see the Advanced menu.
This menu is larger than the normal OSD.
<How to exit the advanced menu>
• Turn off and restart your monitor in the normal way.
To make an adjustment, ensure that the tag is highlighted, then press "SELECT".
To move to another tag, press "EXIT", then press "Left" or "Right" to highlight another tag.
Tag1 Brightness
Contrast
Auto Contrast
(Analog input only)
Auto Black Level
(Analog input only)
ECO Mode
ECO Mode Custom
Auto Brightness
Black Level
AUTO LUMINANCE
NEC MDview 242/242-2
and 262/262-2 only!
Low Bright mode
NEC MDview 262 Only!
Adjusts the overall image and screen background brightness.
Press "Left" or "Right" to adjust.
When AUTO LUMINANCE is OFF or 2, the brightness level is adjusted/measured using
percentage (%).
When AUTO LUMINANCE is 1 or 3, brightness level is adjusted/measured using cd/m
This is the "Estimated Brightness" level.
Adjusts the image brightness and contrast in relation to the background.
Press "Left" or "Right" to adjust.
Adjusts the image displayed for non-standard video inputs. Press "SELECT" to adjust.
Any adjustment requires the image to have white portions.
Automatically adjusts the black level. Any adjustment requires the image to have black
portions. Press "SELECT" to activate Auto Adjust.
Decreases the amount of power consumed by reducing the brightness level.
1: Decreases the brightness by 25%.
2: Decreases the brightness by 50%.
CUSTOM: Decreases the brightness level as determined by the user.
Allows the user to set a preferred brightness level when ECO Mode is in use.
Auto Brightness has three settings.
OFF: No function.
1: Adjusts the brightness automatically, by detecting the brightness level of your
environment and adjusting the monitor with your BRIGHTNESS setting.
2: Adjusts the brightness automatically for the best BRIGHTNESS setting based on the
white display area. The environmental brightness sensor (Ambibright sensor) has no function.
Allows you to manually adjust the black level. Press "Left" or "Right" to adjust.
Stabilizes the luminosity and colour of the image. While the BRIGHTNESS level is
adjusting, the numerical value blinks.
OFF: No function
1: Stabilize Luminance
2: Stabilize Colour
3: Stabilize Luminance and colour
Note: The AUTO LUMINANCE function is only available when "AUTO BRIGHTNESS"
is OFF.
When AUTO LUMINANCE is 1 or 3, maximum value of the Brightness level is limited.
When AUTO LUMINANCE is OFF or 2, the brightness level is adjusted/measured using
percentage (%).
When AUTO LUMINANCE is 1 or 3, brightness level is adjusted/measured using cd/m
This is the "Estimated Brightness" level.
The BRIGHTNESS setting can lower the brightness level.
LOW BRIGHT MODE can be used to lower the brightness even further, if desired.
ON: Brightness is reduced by an additional 50%.
ADVANCED: Brightness is reduced by an additional 25%.
NOTE: When PROGRAMABLE is set for the Gamma Selection (tag5), LOW BRIGHT
MODE is disabled.
English-22
