Specifications - MDview 213
Monitor Specifications
LCD Module
Viewable Image Size: 54 cm/21.3 inches
Native Resolution (Pixel Count): 1600 x 1200
Input Signal
Display Colours
Synchronization Range
Horizontal: 31.5 kHz to 91.1 kHz, 99.4 kHz*
Viewing Angle
Image Formation Time
Resolutions Supported
Active
Landscape: Horiz.: 432 mm/17.0 inches
Display Area
Portrait: Horiz.: 324 mm/12.8 inches
Power Supply
Current Rating
Dimensions
Landscape: 464.8 mm (W) x 424.8 - 574.8 mm (H) x 247.3 mm (D)
Height Adjustment: 150 mm / 5.9 inches (Landscape)
Weight
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Storage Temperature: -10°C to 60°C/14°F to 140°F
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 1200 x 1600 resolution only.
NOTE:
Technical specifications are subject to change without notice.
NEC MDview 213 Monitor
Diagonal: 54 cm/21.3 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7V p-p and Sync Negative 0.3V p-p)
16,777,216
Vertical: 50 Hz to 85 Hz
Left/Right: ±89° (CR > 10)
Up/Down: ±89° (CR > 10)
16 ms (Typ.)
720 x 400*
1
at 70 Hz to 85 Hz
1
640 x 480*
at 60 Hz to 85 Hz
1
800 x 600*
at 56 Hz to 85 Hz
1
832 x 624*
at 75 Hz
1024 x 768*
1
at 60 Hz to 85 Hz
1152 x 864*
1
at 70 Hz to 85 Hz
1152 x 870*
1
at 75 Hz
1280 x 960*
1
at 60 Hz
1
1280 x 1024*
at 60 Hz to 85 Hz
1
1200 x 1600*
at 60 Hz
1600 x 1200 at 60 Hz....................... resolution for optimal display performance.
Vert.: 324 mm/12.8 inches
Vert.: 432 mm/17.0 inches
AC 100-240 V ~ 50/60 Hz
0.68 - 0.29 A (with Option)
18.3 inches (W) x 16.7 - 22.6 inches (H) x 9.7 inches (D)
Portrait: 358.6 mm (W) x 477.9 - 627.9 mm (H) x 247.3 mm (D)
14.1 inches (W) x 18.8 - 24.7 inches (H) x 9.7 inches (D)
10.7 kg (23.6 lbs)
Humidity: 30% to 80%
Altitude: 0 to 10,000 Feet/0 to 3,048 m
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet/0 to 12,192 m
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.270 mm dot pitch;
300 cd/m
typical.
Digital Input: DVI
Depends on display controller used.
2
Automatically
Automatically
8 ms (Gray to gray Typ)
Some systems may not support all modes listed.
NEC DISPLAY SOLUTIONS cites recommended
English-17
2
white luminence; 1000:1 contrast ratio,
