Operating Instructions
GPM 450
Attention
Valid from:
7.6.2010
Issue no.
2
Sheets
6
Advertisement
Table of Contents
Related Manuals for Cyklos GPM 450
Summary of Contents for Cyklos GPM 450
- Page 1 Creasing and Perforating Machine GPM 450 Attention This document including its appendices is exclusive intellectual property of Cyklos (producer cooperative) Choltice. Any other use (copying, distribution or sale) is possible only with approval of the chairman of the cooperative. Valid from:...
- Page 2 Operating Instructions | GPM 450 CONTENTS 1. Safety Risks .............................. 2 2. Technical Parameters ..........................3 3. Machine Description ..........................4 4. Machine Description, Installation and Adjustment ..................5 4.1 Adjustment of Upper Bar Stroke ......................5 5. The Most Common Faults (Troubleshooting) .................... 5 6.
- Page 3 Operating Instructions | GPM 450 2. TECHNICAL PARAMETERS Max. working width 450 mm 80 – 400 g/m² (creasing, punching) Recommended paper grammage 80 – 250 g/m² (perforating) CITO 1.0 mm – paper thickness < 0.4 mm Crease width* (mostly 80 – 150 gsm) CITO 1,4 mm - paper thickness 0,2 - 0,4 mm (mostly 160 –...
- Page 4 Operating Instructions | GPM 450 3. MACHINE DESCRIPTION 1 – Top cover 8 – Lower crease/perf tool 2 – Electric switch 9 – Upper tool locking screws 3 – Rear table 10 – Upper bar 4 – Front table 11 – Clamp 5 –...
- Page 5 Operating Instructions | GPM 450 4. MACHINE DESCRIPTION, INSTALLATION AND ADJUSTMENT Electrical creasing and perforating machine is suited for final processing of graphical material up to 450 mm width. Creasing enables to fold paper easily without cracking. Perforation can be done simply by a blade change, and turning the lower tool (8) without further adjustment.
- Page 6 Operating Instructions | GPM 450 6. MACHINE DISPOSAL After the end of the service life, it is forbidden to dispose of the machine in the municipal waste. The machine must be disassembled, and metallic, non-metallic, plastic, rubber and electronic parts sorted.
