This document including the attachments is exclusive intellectual property of Cyklos Choltice (producer
cooperative). Any other use (copying, distribution or sale) is possible only with approval of the chairman of
Operating Manual
Paper Folding Machine
CFM 600
Effective from serial no.:
Warning
the cooperative.
14011061
Issue No.
3
No. of sheets
8
Advertisement
Table of Contents
Related Manuals for Cyklos CFM 600
Summary of Contents for Cyklos CFM 600
- Page 1 Paper Folding Machine CFM 600 Warning This document including the attachments is exclusive intellectual property of Cyklos Choltice (producer cooperative). Any other use (copying, distribution or sale) is possible only with approval of the chairman of the cooperative. Effective from serial no.:...
- Page 2 Operating Instructions | CFM 600 Content 1. INSTALATION AND OPERATION INFORMATION .................. 3 2. TECHNICAL PARAMETERS ........................4 3. MACHINE DESCRIPTION ........................5 4. OPERATING INSTRUCTIONS ......................... 6 4.1 Automatic paper feeding ........................6 4.2 Stops adjustment, fold type setting ...................... 6 5.
- Page 3 Operating Instructions | CFM 600 1. INSTALATION AND OPERATION INFORMATION a) The folder is designed only for folding paper specified in parameters. b) It is forbidden to fold foils, sheets and similar materials. c) The machine may be utilized only in a closed room (office, shop).
- Page 4 Operating Instructions | CFM 600 2. TECHNICAL PARAMETERS 70 - 120 listů / min. ± 15 % (A4) Folding speed Types of folds standard letter concertina single double parallel (<160 g/m²) brochure half concertina Sheet size A3 , (B4), A4 , (B5), A5 .
- Page 5 Operating Instructions | CFM 600 3. MACHINE DESCRIPTION start/stop button speed control button feeding tray tilting board feeding board arrestment lever light bulb control delivery drawer stop X stop Y 10 ruler 11 side guides 12 front cover 13 arrestment button...
- Page 6 Operating Instructions | CFM 600 4. OPERATING INSTRUCTIONS 4.1 Automatic paper feeding Insert the feeding board arrestment lever 5 into its lower position. Feed the paper on the tilting board 4 – being tilted away at the moment, placing it between side guides 11 which are set approximately to the required paper width.
- Page 7 Operating Instructions | CFM 600 5. TROUBLESHOOTING Paper jams in the machine: Both stops must be removed from the machine and the sheet must be removed so that the rollers can turn over spontaneously. LED light is blinking: the stops are in incorrect position or there is a paper missing on the feeding tray, or the paper got stuck in the machine 6.
