Cyklos CFM 500 Operational Manual

PAPER FOLDING MACHINE CFM 500

1) Parameters

- folding speed
methods of folding
-
- sheet format
- basis weight
- input board capacity
- machine dimensions: working position - l = 295 mm,
machine weight
-
- voltage / frequency
electric input
-
electric current
-
- fuse

2) Machine description

WARNING:
a) The folder is designed only for folding paper specified in parameters.
b) It is forbidden to fold foils, sheets and similar materials.
c) The machine may be utilized only in a closed room (office, shop).
d) It is forbidden to utilize the machine outdoors.
e) It is forbidden to utilize the machine with damaged feeding cord.
f) It is forbidden to utilize the machine, if unusual sounds are heard.

INSTALLATION AND OPERATING INSTRUCTIONS

a) It is forbidden to operate the machine under a voltage different from the voltage
specified on the type label.
b) Prior to the machine utilization, definitely read all instructions.
c) To reduce the risk of injury, an inspection shall be essential, if the product
utilized in the vicinity of children.
d) It is forbidden to insert fingers or hands to the product after the feeding cord
connecting.
e) If the machine blocked, it shall be first necessary to disconnect the machine
from the mains supply, and then remove the cause of blocking.
f) It is forbidden to replace faulty fuse by another type, or by a fuse with different
power.
OPERATIONAL MANUAL
120 sheets/min.
standard letter, concertina, single
A4, A5, A6
80 -120 g / m²
200 sheets (80 g/m²)
transport position - l = 295 mm
15 kg
230 V / 50 Hz
60 W
300 mA
F 630 mA/250V
1
w = 355 mm,
h = 365 mm
w = 355 mm
h = 280 mm
