Dimensions (Direct View)
W1
H2
H1
W2
NOTE: Please see CAD files for additional dimensional data.
W1
1200mm / 48"
24.5mm / 0.96"
33.3mm / 1.31"
300mm / 12"
24.5mm / 0.96"
33.3mm / 1.31"
Dimensions (Diffused View)
W1
H2
H1
W2
NOTE: Please see CAD files for additional dimensional data.
W1
1200mm/ 48"
24.5mm / 0.96"
33.3mm / 1.31"
300mm / 12"
24.5mm / 0.96"
33.3mm / 1.31"
Tube-to-tube Clearance
To maintain consistent LED pitch and to allow for thermal expansion, a minimum of
4mm / 0.16" is required between luminaire's.
>4mm / 0.16"
Tube-to-tube Connection
www.traxon-ecue.com
Mounting Guide
Allegro Media Tube
L1
A
W2
H1
H2
58.2mm / 2.29"
31.2mm / 1.23"
58.2mm / 2.29"
31.2mm / 1.23"
L1
A
W2
H1
H2
70mm / 2.76"
43mm / 1.69"
70mm / 2.76"
43mm / 1.69"
If you do not hear "click", rotate the spring loaded
connector manually to ensure that the connectors
are properly mated.
1
2
Lite
®
Mounting Guide
L
D
L
L1
A
A
D
240mm / 9.45"
850mm / 33.46"
145mm / 5.71"
135mm / 5.31"
L
D
L
L1
A
A
D
240mm / 9.45"
850mm / 33.46"
145mm / 5.71"
135mm / 5.31"
If you do not hear "click", rotate the spring loaded connector manually to ensure that the
connectors are properly mated.
08/23 V1.1
L2
L2
D
L
L1
1200mm / 47.24"
116.5mm / 4.59"
300mm / 11.81"
116.5mm / 4.59"
L2
L2
D
L
L1
1200mm / 47.24"
116.5mm / 4.59"
300mm / 11.81"
116.5mm / 4.59"
End Cap Seal on Last Tube
©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED.
L2
136.3mm / 5.37"
136.3mm / 5.37"
L2
136.3mm / 5.37"
136.3mm / 5.37"
1 of 3
