- Page 1 TFS230 FLOOR STRIPPER OPERATION AND MAINTENANCE MANUAL www.trelawny.co.uk 735.5230...
-
Page 2: Table Of Contents
Notes ....................................16 INTRODUCTION Your new Trelawny SPT power tool will more than satisfy your expectations. It has been manufactured under stringent Trelawny SPT Quality Standards to meet superior performance criteria. You will find your new tool easy and safe to operate, and, with proper care, it will give you many years of dependable service. - Page 3 www.trelawny.co.uk...
- Page 4 TFS230 Floor Stripper PAGE 4...
-
Page 5: Declaration Of Conformity
73/23/EC DIREKTIVA O STROJIH Z NIZKO VOLTAŽO (nanaša se samo na proizvode na električni pogon) MEGFELELŐSÉGI NYILATKOZAT UYGUNLUK BEYANI Mi. A "Trelawny SPT Limited" cég Trelawny SPT Limited Felelösségünk tudatában kijelentjük, hogy mint a termék szállitója/gyartója AÞaöýdaki, üretim ve tedarikinden tek baÞýna sorumlu olduöu ürünün Termék neve... -
Page 6: General Information
TFS230 Floor Stripper GENERAL Information Thank you for your purchase of the Trelawny TFS230 Floor The machine is primarily designed for the removal of bonded stripper. Before operating the TFS230 this manual must be carpet, vinyl, linoleum, cork, and other floor covering. It can be... -
Page 7: Risk Of Hand-Arm Vibration Injury
4 bolts and washers. Fit all four bolts loosely first, then tighten fully. STEP 2 Pull the knob on lower handle and slide upper handle into lower handle tube. Secure by turning knob until upper handle is securely clamped in place. www.trelawny.co.uk... -
Page 8: Pre Start Checks (Daily)
4mm extension cable up to a maximum of 20 metres, as The TFS230 is supplied with a specially commissioned electric it draws a significant operating current. The use of 2.5mm motors and starter box assembly. Each unit is fully tested 110v machines is not recommended and can cause operating and set according to the manufacture’s specifications. -
Page 9: Handle Adjustment
(DO NOT REMOVE COMPLETELY) STEP 3 Remove blade holder. STEP 4 Replace blade. STEP 5 Secure the blade holder back into place and tighten screws. CAUTION: BLADES ARE SHARP! Observe PPE & safety precautions when changing blades. www.trelawny.co.uk... -
Page 10: Blade Angle Adjustment
TFS230 Floor Stripper Blade Angle Adjustment STEP 1 Loosen (do not remove) the T-handle on the left side of the TFS230, located above the back left hand wheel. STEP 2 Lift handle upwards (rear wheels should remain on the ground). -
Page 11: Machine Operation
2. Manually remove any nails, studs, pins, rebar etc. from 7. The TFS230 is designed to be used in a forward motion; the area to be stripped before starting work. Attempting to the oscillation of the blade also helps with the operation. The... -
Page 12: Exploded View
TFS230 Floor Stripper EXPLODED VIEW TABLE 1: ELECTRICAL ENCLOSURE CONFIGURATION TABLE Machine Electrical Enclosure Description Assembly 323.2402 TFS - 110V 990.0033 323.2404 TFS - 230V 990.0034 DETAIL C 48 60 PAGE 12... -
Page 13: Wiring Diagrams
Thermal MOTOR Breaker 230V Wiring Line Power Relay 2.5sqmm Power signal flow direction 6(14) 1(A1) through the circuit 8(11) Internal Single core cable 2.5sqmm size 2.5sqmm Arm/Power Cable size 2.5sqmm Loop Connection AC Input (Motor) Loop Cable size (1.5sqmm) www.trelawny.co.uk... -
Page 14: Parts List Tfs230
TFS230 Floor Stripper Parts List TFS230 ITEM NO. PART NO. DESCRIPTION 990.0011 TFS - Chassis Metalwork Assy 1 990.0035 TFS - Stripper Arm Wear Strip Assembly 1 853.0830 M8 x 30mm CSK Socket Head Screw 2 875.1270 M10 Square Nut (DIN 557) 2 990.0014... -
Page 15: Technical Specification
Stripping sheet materials, such as vinyl or Use a knife to score the material into strips of approximately same with as carpet. TFS230 blade before starting work. Eccentric bearing failure. Replace. Switch off & Isolate power to machine. Carefully inspect motor & free-moving Motor/drivetrain wear. -
Page 16: Notes
TFS230 Floor Stripper Notes PAGE 16... - Page 17 Notes www.trelawny.co.uk...
- Page 18 TFS230 Floor Stripper Notes PAGE 18...
- Page 19 All rights reserved. Any unauthorised use or copying of the contents or part thereof is prohibited. This applies to trademarks, model denominations, part numbers and drawings. Use only genuine Trelawny spares. The use of non-Trelawny spare parts invalidates the warranty.
- Page 20 Trelawny House, 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa, Warwickshire, CV31 1XT, United Kingdom Leamington Spa, Warwickshire, CV31 1XT, United Kingdom Telephone: +44 (0)1926 883781 Fax: +44 (0)1926 450352 Email: sales@trelawny.co.uk Website: www.trelawny.co.uk Telephone: +44 (0)1926 883781 Fax: +44 (0)1926 450352 Email: sales@trelawny.co.uk...
