- Page 1 TPG650 PLANETARY FLOOR GRINDER OPERATION & MAINTENANCE...
-
Page 2: Operation
TPG650, please do not hesitate to contact your local Trelawny dealer or DO NOT OPERATE ELECTRIC agent. alwa ys welc om e VERSIONS IN WET CONDITIONS. - Page 3 Media Types - Metal Bond Tools Image Part Number Tool Description PCD Removal Diamond Anti Clock Wise 365.5495L For removal of coatings, adhesives & toppings PCD Removal Diamond Clock Wise 365.5495R For removal of coatings, adhesives & toppings 16 Grit Single (Quick Release) Soft Bond 365.5500 For very course grinding and thin coating removal 16 Grit Double (Quick Release) Soft Bond...
- Page 4 1500 Grit Resin Bond 365.5635A 3000 Grit Resin Bond 350.5666 Polishing Adapter Plate Used to attach the “Polishing Tools” to the quick release plate 365.5745 3 Segment Polishing Plate (Set of 3) Used to attach “Polishing Tools” For use only on the TPG650/540...
-
Page 5: Maintenance
Button” “REV” - Reverse. tightness. Ensure that all fittings are secure. Machine Operation The TPG650 is supplied with a Connect a suitable commercial specially commissioned frequency vacuum which has been designed inverter, starter switch and electric for the collection of concrete dust motor. -
Page 6: Machine Storage
Maintenance Shut Down Old Screw Fit System: Carefully tilt the machine backwards Simply Press the Black „STOP‟ After removing the plate from the to rest on its handle bar. Button. machine (Using the steps provided After the machine has completely previously). - Page 7 Exploded View - Gear Box...
- Page 9 Exploded View - Plate Holder...
- Page 10 Parts List - Plate Holder ITEM No Part No Description 365.2260H Driving Disk Ring 365.2260I Driving Disk - Coupling 365.2260G Driving Disk- Stud Ring 365.2260K Driving Disk Base 365.2260L Disk Holding Pin 365.2248C Oil Seal Ø 62 x Ø 45 x 9 365.2260A Axis Coupling 365.2260B...
- Page 11 Exploded View - Machine Assembly...
- Page 12 Parts List - Machine Assembly ITEM No Part No Description 13- 15 365.2230A Motor Support 365.2230B Holding Block 365.2230C Dust Cover Support 365.2225 Dust Cover 365.2242 Oil Seal Ø120 x Ø150 x 12 365.2243 Oil Seal Ø130 x Ø160 x 12 365.2241A Motor Coupling part on Motor Shaft 365.2241B...
- Page 13 Electrical Control Box - Parts Part Part No Description M22-A 365.9570A Fixing Adaptor M22-K01 365.9570B Contact Block M22-K10 365.9570C Contact Block M22-LED-W 365.9570D LED Element M22-PV 365.9570E Emergency Stop Button M22-XZK-GB99 365.9570F E-stop label 33x50mm M22-WRK3 365.9570G 3 Position 60° Rotary Switch M22-R4K7 365.9570H...
-
Page 14: Fault Finding
The motor runs but nothing The main belt has broken, contact your nearest reseller. turns underneath. If problem has not been cured by any of the above actions, contact your local Trelawny SPT dealership for assistance. FREQUENCY CONVERTER MONITOR ERROR CODES... -
Page 15: Technical Specifications
Use only genuine Trelawny spares. The use of non-Trelawny spare parts invalidates the warranty. SURFACE PREPARATION TECHNOLOGY Trelawny SPT Ltd Trelawny House, 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa, Warwickshire, CV31 1XT, United Kingdom Telephone: +44 (0)1926 883781 Fax: +44 (0)1926 450352 Email: sales@trelawny.co.uk...
