- Page 1 DISCOVERY SERIES Ceiling Fan Instruction Book Models: MDF124 MDF134 MDF1243 MDF1343 DESCRIPTION QUANTITY Motor assembly Instruction manual Screw kit Balancing kit Hanging bracket Wall control kit Blades...
- Page 2 ONLY install the remote controller kit that comes supplied by Martec Pty Ltd within package. DO NOT control operation of fan and light with any other remote control than what was approved by Martec Pty Ltd and supplied within this package, as this will void warranty.
- Page 3 With Light Hanging Plate Wall Control Hanging Ball Down Rod Canopy Cover Reverse Switch Housing Cover Blade Rotating Ring Light Plate Glass Without Light Hanging Plate Wall Control Hanging Ball Down Rod Canopy Cover Reverse Switch Cover Blade Housing Rotating Ring Cover www.martecaustralia.com.au | 02 8778 7500 | sales@martecltd.com.au Page 3...
- Page 4 Secure the hanger bracket to ceiling beam or a suitable piece of timber inserted between the ceiling beams. Martec Pty Ltd recommends the bracket to be attached with two long screws as supplied within the package. Place circular shockproof gasket above the hanger bracket. Align the bracket and screw the hanger bracket to the ceiling tightly.(See Fig.1.)
- Page 5 HOW TO REMOVE THE SHADE FOR INSTALLING LED LIGHT PLATE (Version with lights) Remove the Glass Shade carefully as shown . Turn anticlockwise to remove and clockwise to tighten the glass shade. (See Fig.5.) Fig.5 Tricolour CCT (Colour changeable temperature) Please make sure the switch is off before changing the colour temperature.
- Page 6 WIRING INSTRUCTIONS www.martecaustralia.com.au | 02 8778 7500 | sales@martecltd.com.au Page 6...
