STUDER Innotec SA
STUDER Innotec SA
User manual- Manuel utilisateur-Betriebsanleitung-Manual utilizador
Appendix 1
XTH 3000-12
XTH 5000-24
XTH 6000-48
XTH 8000-48
This appendix is part of the installation and user manual
Cette annexe fait partie intégrante du manuel d'utilisation
Dieser Anhang ist ein wesentlicher Bestandteil des Betriebsanleitung
Este anexo es parte integrante del manual de utilización
Appendix 1
Annexe 1
XTM 1500-12
XTM 2000-12
XTM 2400-24
XTM 3500-24
XTM 2 00-48
XTM 4000-48
-
Temp.
CAN
Battery
Bus
Sens.
T
Xtender
Aux1
Aux2
G
1
Anhang 1
6
+
Remote
On/Off
(Command
entry)
AC IN
AC OUT
L
N
L
N
V4.2.3
Xtender
Anexo 1
XT
S 9
00-12
XT
S 12
00-
24
XT
S 1
400-
48
P.
Advertisement
Related Manuals for Studer Innotec SA XTH 3000-12
Summary of Contents for Studer Innotec SA XTH 3000-12
- Page 1 STUDER Innotec SA STUDER Innotec SA Xtender User manual- Manuel utilisateur-Betriebsanleitung-Manual utilizador Appendix 1 Annexe 1 Anhang 1 Anexo 1 XTM 1500-12 XTH 3000-12 00-12 XTM 2000-12 XTH 5000-24 S 12 XTM 2400-24 XTH 6000-48 400- XTH 8000-48 XTM 3500-24...
- Page 2 STUDER Innotec SA Xtender Appendix 1 V4.2.3...
- Page 3 STUDER Innotec SA Xtender Appendix 1 V4.2.3...
- Page 4 STUDER Innotec SA Xtender OTE IMPORTANTE Cette annexe au manuel est commune à toutes les langues et doit être conservée avec le manuel de la langue de votre choix. Pour la bonne compréhension de ce document, vous devez vous référer aux commentaires des éléments référencés par des lettres ou des chiffres dans les chapitres suivants du manuel :...
- Page 5 STUDER Innotec SA Xtender Fig. 1a Model and specification tag 30 32 XTH 5000-24 XTM 3500-24 Model: Uac In....230V (150V-265V) 00352 XXFN Pnom/P30..3000VA / 3500VA Iac In max.... Udc Battery..24Vdc (18Vdc-34Vdc) Uac Out....230V (150V-245V) RoHS www.studer-innotec.com Idc Charge/Inv..
- Page 6 STUDER Innotec SA Xtender Fig. 2a Dimension, clearance and affixing 300mm 20cm 160mm d=8mm 20cm 230mm 20cm 220mm d=8mm 20cm 20cm d=8mm 84 mm 120 mm 205 mm 256 mm 130mm d=8mm 323 mm Appendix 1 V4.2.3...
- Page 7 STUDER Innotec SA Xtender Fig. 5a Fig. 5b 12V battery bank wiring 12V battery bank with 2Vcell in series and wiring with single and parallel+series parallel 12Vcell Fig. 5c Fig. 5e 24V battery bank wiring 24V battery bank with 2Vcell in serie and...
- Page 8 STUDER Innotec SA Xtender 48V battery bank wiring with Fig. 6a series/parallel 12Vcells Fig. 6b 48V battery bank wiring with series 12Vcells Fig. 6c 48V battery bank wiring with 24 x 2Vcell in series Fig. 6d 48V battery bank wiring with 2...
- Page 9 STUDER Innotec SA Xtender Fig. 7a Xtender XTS principle and equivalent schematic BATTERY >1mF Xtender Multimode L1 L2 L3 Power Center AC out Search AC in Limit Restart Charge U/Uo Fault TCM-01 (XTS only) Temp. RJ45 RJ11 RJ11 RCM/10 BTS-01 ARM-02 termin.
- Page 10 STUDER Innotec SA Xtender Fig. 7b Xtender principle and equivalent schematic XTH / BATTERY >1mF 4,7K Remote 4,7K entry Temp. termination Main On/Off only max 300m RCC-02 Main On/Off only RJ45 RJ11 Temp. termination Remote entry Main On/Off RCM-10 Appendix 1...
- Page 11 STUDER Innotec SA Xtender Fig. 8a Fig. 8b Wiring exemple of a single phase Wiring variants for system (AC and DC side). remote control ON/OFF Max.lengh:5m. Max.U: 60 Veff Max. I < 30mA Remote Temp. Remote Battery On/Off Sens. On/Off...
- Page 12 STUDER Innotec SA Xtender Fig. 9a Wiring example of single phase with plugged generator Secured loads Unsecured loads Fig. 9b Wiring example of triphase in with plugged Xtender Secured loads Unsecured loads Appendix 1 V4.2.3...
- Page 13 STUDER Innotec SA Xtender Fig. 10a Wiring example of a vehicle plugable on AC grid loads Fig. 10b Wiring example of a boat plugable on shore AC source without isolation transformer Fig. 10c Wiring example of a boat plugable on shore...
- Page 14 STUDER Innotec SA Xtender Fig. 11 Wiring example of a hybrid system with , wind or hydro source Temp. Remote Battery On/Off Sens. (Command entry) Xtender AC IN AC OUT Aux1 Aux2 Appendix 1 V4.2.3...
- Page 15 STUDER Innotec SA Xtender Fig. 12 Wiring example of 3 units paralleled in BTS-01 single phase Remote Remote Remote Temp. Temp. Temp. Battery Battery Battery On/Off On/Off On/Off Sens. Sens. Sens. Xtender Xtender Xtender AC IN AC OUT AC IN...
- Page 16 STUDER Innotec SA Xtender Fig. 13 Wiring example of 3 units in three-phase BTS-01 Temp. Temp. Remote Temp. Remote Remote Battery Battery Battery Sens. Sens. On/Off Sens. On/Off On/Off Xtender Xtender Xtender AC IN AC OUT AC IN AC OUT...
- Page 17 STUDER Innotec SA Xtender Fig. 14 Wiring exemple of 3 units in three-phase BTS-01 with single phase ACsource Temp. Temp. Temp. Remote Remote Remote Battery Battery Battery Sens. Sens. Sens. On/Off On/Off On/Off Xtender Xtender Xtender AC IN AC OUT...
- Page 18 STUDER Innotec SA Xtender Fig. 15 Wiring example of 3 units in three-phase + one phase (L3) paralled BTS-01 Temp. Temp. Temp. Temp. Remote Remote Remote Remote Sens. Sens. Sens. Sens. Battery Battery Battery Battery On/Off On/Off On/Off On/Off Xtender...
- Page 19 STUDER Innotec SA Xtender Fig. 16 Wiring example of 3 Xtender Xtender Xtender units paralleled and in three-phase AC IN AC OUT AC IN AC OUT AC IN AC OUT Xtender Xtender Xtender AC IN AC OUT AC IN AC OUT...
- Page 20 STUDER Innotec SA Xtender Fig. 17 DC bus wiring example of 3 units paralleled and in three-phase Temp. Temp. Temp. Remote Remote Remote Battery Battery Battery Sens. Sens. Sens. On/Off On/Off On/Off Xtender Xtender Xtender AC IN AC OUT AC IN...
- Page 21 STUDER Innotec SA Xtender Fig. 18 DC side star wiring example of 3 units paralleled and in three-phase Temp. Temp. Temp. Remote Remote Remote Battery Battery Battery Sens. Sens. Sens. On/Off On/Off On/Off Xtender Xtender Xtender AC IN AC OUT...
- Page 22 STUDER Innotec SA Xtender Fig. 19 Wiring exemples of max 3 remote control RCC-02/03 conected on Xtender to control multiple Xtender system L max (e+e+e)=100m Temp. Temp. Temp. Sens. Sens. Sens. Xtender Xtender Xtender L max (e+e)=150m L max (e)=300m Temp.
- Page 23 STUDER Innotec SA Xtender Fig. 20 Wiring exemple of 2 units in split-phase Secured loads Unsecured loads Appendix 1 V4.2.3...
- Page 25 STUDER Innotec SA Xtender Studer Innotec SA Rue des Casernes 57 1950 Sion – Switzerland Tél : +41(0) 27 205 60 80 Fax : +41(0) 27 205 60 88 info@studer-innotec.com www.studer-innotec.com Appendix 1 V4.2.3...
